Computer Simulation of Fracture Process in Compressive Failure of Cross-Ply Laminate of Composite Materials

Abstract:

This study investigates the computer simulation of fracture process in compressive failure of cross-ply laminate of composite materials. The purpose of this study is to establish the numerical analysis method to understand the fracture mechanism and predict the mechanical response of composite materials through the computer simulation. The stacking sequence of the simulated laminate is [0/90] s. The reinforcement fibers in 0-degree plies are modeled by circle cross-section beam elements to represent the three-dimensional effect in bending of fibers. Cohesive elements are inserted in the connection of beam elements to simulate the bending breaking of fibers. For the purpose of parallel computing, the domain decomposition method is applied, and for pre-conditioned conjugate gradient algorithm, incomplete Cholesky conjugate gradient method is applied. The simulated results show that in the initial state of the loading, the stress concentration occurs around the initial misalignment of fiber in 0-degree plies, and it also occurs around the area where fibers come close in 90-degree plies. At average applied strain 1.20 %, the fiber breaking damage initiates in 0-degree ply, and after this point the damage develops in the material. The simulated damage is close to the microscope picture of the actual composite materials obtained in the experiment. The current simulation is considered to correspond with the actual material deformation.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 549-556
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.549
• Online since: October 2014
• Authors: Takeaki Nadabe*, Nobuo Takeda
• Keywords: Composite Material, Computer Simulation, Domain Decomposition Method, Fracture Mechanism, Parallel Computing

References

[1] M.J. Hinton, P.D. Soden, Predicting failure in composite laminates: the background to the exercise, Compos. Sci. Technol. 58 (1998) 1001-1010.

DOI: 10.1016/s0266-3538(98)00074-8

[2] C.R. Schultheisz, A.M. Waas, Compressive failure of composites, Part I: Testing and micromechanical theories, Prog. Aerosp. Sci. 32 (1996) 1-42.

DOI: 10.1016/0376-0421(94)00002-3

[3] A.M. Waas, C.R. Schultheisz. Compressive failure of composites, Part II:, Experimental studies, Prog. Aerosp. Sci. 32 (1996) 43-78.

DOI: 10.1016/0376-0421(94)00003-4

[4] J. LLorca, C. González, J.M. Molina-Aldareguía et al., Multiscale modeling of composite materials: a roadmap towards virtual testing, Adv. Mater. 23 (2011) 5130-5147.

DOI: 10.1002/adma.201101683

[5] E. Totry, C. Gonzalez, J. LLorca, Failure locus of fiber-reinforced composites under transverse compression and out-of-plane shear, Compos. Sci. Technol. 68 (2008) 829-839.

DOI: 10.1016/j.compscitech.2007.08.023

[6] E. Totry, C. Gonzalez, J. LLorca, Prediction of the failure locus of C/PEEK composites under transverse compression and longitudinal shear through computational micromechanics, Compos. Sci. Technol. 68 (2008) 3128–3136.

DOI: 10.1016/j.compscitech.2008.07.011

[7] E. Totry, C. Gonzalez, J. LLorca, Influence of the loading path on the strength of fiber-reinforced composites subjected to transverse compression and shear, Int. J. Solids Struct. 45 (2008) 1663–1675.

DOI: 10.1016/j.ijsolstr.2007.10.014

[8] P.D. Soden, M.J. Hinton, A.S. Kaddour, Lamina properties, lay-up configurations and loading conditions for a range of fibre-reinforced composite laminates, Compos. Sci. Technol. 58 (1998) 1011-1022.

DOI: 10.1016/s0266-3538(98)00078-5
