Investigation of Boiling Heat Transfer and Flow Regimes in a Heat Exchanger

Abstract:

Experimental and numerical simulation of heat transfer and flow regimes for vertical flow across horizontal tubes are presented for mass flow rate in the range 0.03 – 0.17 kg/s and heat fluxes in the range 1.07–1.35 kW/m². The tubes had a diameter of 9.75 mm and a pitch to diameter ratio of 1.85. The CFX version 14.0 from ANSYS was used to predict the flow regimes and the temperature distribution in the tube bundles. These data and the predictions from numerical simulation were compared with the data available in the literature. It is found that the circulation zone in the shell becomes bigger as the mass flow rate is increases. The flow patterns identified in this experiment are bubbly, intermittent and annular flow. These data agrees well with the published data.

You might also be interested in these eBooks

Advances in Mechanical, Materials and Manufacturing Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 660)

Pages:

679-683

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.660.679

Citation:

Cite this paper

Online since:

October 2014

Authors:

Azmahani Sadikin*, Muhammad Adib Jamil, Norasikin Mat Isa

Keywords:

Boiling, CFD, Flow Pattern, Heat Exchanger

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] G. E. Alves, Cocurrent Liquid-Gas Flow in Pipe-Line Contactor, Chemical Engineering Progress Vol. 50(9) (1954) 449-456.

Google Scholar

[2] J. W. Coleman, S. Garimella, Two-phase flow regimes in round, square and rectangular tubes during condensation of refrigerant R134a, International Journal of Refrigeration 26 (2003) 117–128.

DOI: 10.1016/s0140-7007(02)00013-0

Google Scholar

[3] D. A. McNeil, K. Bamardouf, B. M. Burnside, M. Almeshaal, Investigation of flow phenomena in a kettle reboiler, International Journal of Heat and Mass Transfer, 53(5-6) (2010) 836–848.

DOI: 10.1016/j.ijheatmasstransfer.2009.11.041

Google Scholar

[4] N. Yusuf, Y. Al-Wahaibi, T. Al-Wahaibi, A. Al-Ajmi, A.S. Olawale, I.A. Mohammed, Effect of oil viscosity on the flow structure and pressure gradient in horizontal oil–water flow, Chemical Engineering Research and Design, 90(8) (2012) 1019–1030.

DOI: 10.1016/j.cherd.2011.11.013

Google Scholar
