Fabrication Techniques for PDMS Dome-Shaped Membrane Using Soft Lithography Process

Abstract:

The dome-shaped membrane is very important part of the micro/nano devices. The dome-shaped with the thickness of 150 μm and a radius of 3.2 mm was fabricated using the soft lithography process. The Polydimethylsiloxane (PDMS) was selected as a material because it deformable and suitable to implement as a membrane. Soft lithography is based on pattern transfer using a mold that is patterning the substrate material. In this paper, two techniques were suggested to fabricate the dome-shaped membrane which are reflow technique and stamping technique. The comparison was made for both techniques using a Scanning Electron Microscope (SEM) and it seems the stamping technique has an advantage where the uniform thickness of the dome-shaped membrane can be achieved. The discussion on the temperature effect of a stamping technique shows that the suitable temperature to harden the PDMS is in temperature room where the bubbles can be eliminated under this temperature.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 899-903
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.899
• Online since: October 2014
• Authors: Mohd Norzaidi Mat Nawi*, Asrulnizam Abd Manaf, Mohd Rizal Arshad, Othman Sidek
• Keywords: Dome-Shaped, Membrane, PDMS, Soft-Lithography

References

[1] M.N.M. Nawi, A.A. Manaf, M.R. Arshad, O. Sidek, Modeling of Novel Microfluidic based Flow Sensor Inspired from Fish Canal Neuromast for Underwater Sensing, Jurnal Teknologi (Science and Technology) 62 (2013) 33-38.

DOI: 10.11113/jt.v62.1316

[2] G. Kwon, F. Arai, T. Fukuda, K. Itoigawa, and Y. Thukahara, Dome shaped touch sensor using PZT thin film made by hydrothermal method, IEEE International Conference on Robotics and Automation (2001) 577-582.

DOI: 10.1109/robot.2001.932612

[3] M.S. Kim, S.E. Jo, D.H. Kang, H.R. Ahn and Y.J. Kim, A dome shaped piezoelectric tactile sensor array using controlled inflation technique, The 17th International Conference on Solid-State Sensors, Actuators and Microsystems (TRANSDUCERS & EUROSENSORS XXVII) (2013).

DOI: 10.1109/transducers.2013.6627161

[4] J. Oh, G. Kim, F. Kralick and H. Noh, Design and Fabrication of a PDMS/Parylene Microvalve for the Treatment of Hydrocephalus, Journal of Microelectromechanical Systems 20 (2011) 811-818.

DOI: 10.1109/jmems.2011.2148158

[5] J-C. Chou, D-G Wu, S-C. Tseng, S-C. Chen, G-C. Ye, Application of Microfluidic Device for Lactic Biosensor, IEEE Sensors Journal 13(2013) 1363-1370.

DOI: 10.1109/jsen.2012.2234552

[6] C. Liu, Recent developments in polymer MEMS, Advanced Materials, 19(2007) 3783-3790.

[7] V. Senez, E. Lennon, S. Ostrovidov, T. Yamamoto, H. Fujita, Y. Sakai and T. Fujii, Integrated 3-D Silicon Electrodes for Electrochemical Sensing in Microfluidic Environments: Application to Single-Cell Characterization, IEEE Sensors Journal 8 (2008).

DOI: 10.1109/jsen.2008.918948

[8] G.M. Whitesides, E. Ostuni, S. Takayama, X. Jiang and D.E. Ingber, Soft lithography in biology and biochemistry, Annual review of biomedical engineering 3(2001) 335-373.

DOI: 10.1146/annurev.bioeng.3.1.335

[9] Y. Xia and G.M. Whitesides, Soft lithography, Annual review of materials science, 28(1998) 153-184.

[10] S. Herber, J. Bomer, W. Olthuis, P. Bergveld, and A. Van Den Berg, A miniaturized carbon dioxide gas sensor based on sensing of pH-sensitive hydrogel swelling with a pressure sensor, Biomedical microdevices, 7(2005) 197-204.

DOI: 10.1007/s10544-005-3026-5
