Heat Transfer Characteristic of Thermal Barrier Coated Piston Crown for a Compressed Natural Gas Direct Injection Engine

Abstract:

Compressed natural gas with direct injection (CNGDI) engine produces high temperature and pressure ultimately leading to high thermal stress. The piston crown material fails to withstand high temperature and operate ineffectively due to improper heat transfer. By insulating the surface namely; thermal barrier coating (TBC) such as ceramic based yttria partially stabilised zirconia (YPSZ), heat transfer to the piston might be reduced and lead to improvement of piston durability. Hence, in this research, YPSZ/NiCrAl coating was utilised to differentiate with the uncoated piston crowns in terms of the ability to reduce thermal stresses to the piston using finite element method and burner rig test. Several samples of AC8A aluminium alloy piston crowns were coated with bonding element of NiCrAl and ZrO₂-7.5Y₂O₃ namely the YPSZ as the top coat by using air-plasma spraying technique and were assessed by burner rig test. The results exhibited the durability of the YPSZ/NiCrAl coating could withstand the test and the heat flux for the YPSZ/NiCrAl-coated piston crown was about 98% reduction compared to the uncoated piston crown. Also, the lower the gradient value of the heat flux, the higher the heat resistance.

• Periodical: Applied Mechanics and Materials (Volume 663)
• Pages: 304-310
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.663.304
• Online since: October 2014
• Authors: Ahmad Jalaludin Helmisyah*, Shahrir Abdullah, Mariyam Jameelah Ghazali
• Keywords: Compressed Natural Gas Direct Injection, Finite Element Analysis (FEA), Heat-Flux, Piston Crown, Plasma Spray, Thermal Barrier Coatings

References

[1] W.H. Kurniawan, S. Abdullah, A. Shamsudeen, Turbulence and heat transfer analysis of intake and compression stroke in automotive 4-stroke direct injection engine, Algerian J. of Appl. Fluid Mech. 1 (2007) 37-50.

[2] W.H. Kurniawan, S. Abdullah, Numerical analysis of the combustion process in a four-stroke compressed natural gas with direct injection system, J. Mech. Sci. & Tech. 22 (2008) 1937-(1944).

DOI: 10.1007/s12206-008-0737-6

[3] S. Abdullah, W.H. Kurniawan, A. Shamsudeen. Numerical analysis of the combustion process in a compressed natural gas direct injection engine, J. Appl. Fluid Mech. 1(2) (2008) 65-86.

[4] E. Adril, S. Abdullah, A.K. Ariffin, A. Muchtar, K. Omar, Comparative study of characteristic of lubricant oils in gasoline and compressed natural gas engines, European J. Sci. Research. 30, 2 (2009) 282-293.

[5] S. Abdullah, E. Adril, A. Muchtar, A.K. Ariffin, Friction reduction in compressed natural gas direct injection engine using piston rings with diffusion chromium coating, J. Appl. Sci. 10, 6 (2010) 462-470.

DOI: 10.3923/jas.2010.462.470

[6] F.S. Silva, Fatigue on engine pistons – a compendium of case studies, Eng. Fail. Analysis. 13 (2006) 480-492.

DOI: 10.1016/j.engfailanal.2004.12.023

[7] T.M. Yonushonis, Overview of thermal barrier coatings in diesel engines, J. Ther. Spray Tech. 6, 1 (1997) 50-56.

DOI: 10.1007/bf02646312

[8] E. Buyukkaya, Thermal analysis of functionally graded coating AlSi alloy and steel pistons, Surf. Coat. Tech. 202 (2008) 3856-3865.

DOI: 10.1016/j.surfcoat.2008.01.034

[9] A. Tricoire, B. Kjellman, J. Wigren, M. Vanvolsem, L. Aixala, Insulated piston heads for diesel engines, J. Ther. Spray Tech. 18, 2 (2009) 217-222.

DOI: 10.1007/s11666-009-9301-x

[10] A.J. Helmisyah, S. Abdullah, M.J. Ghazali, Effect of thermal barrier coating on piston crown for compressed natural gas with direct injection engine, Appl. Mech. and Mat. 52-54 (2011) 1830-1835.

DOI: 10.4028/www.scientific.net/amm.52-54.1830

[11] A.J. Helmisyah, S. Abdullah, M.J. Ghazali, B. Abdullah, N.R. Abdullah, Effect of extreme temperatures on coated piston crown for CNGDI engine, Appl. Mech. & Mat. 393 (2013) 281-286.

DOI: 10.4028/www.scientific.net/amm.393.281

[12] A. Uzun, I. Cevik, M. Akcil, Effects of thermal barrier coating on a turbocharged diesel engine performance, Surf. Coat. Tech. 116-119 (1999) 505-507.

DOI: 10.1016/s0257-8972(99)00099-7

[13] T. Hejwowski, A. Weronski, The effect of thermal barrier coating on diesel engine performance, Surf. Eng., Surf. Instru. and Vac. Tech. 65 (2002) 427-432.

DOI: 10.1016/s0042-207x(01)00452-3

[14] S.H. Chan, K.A. Khor, The effect of thermal barrier coated piston crown on engines characteristics, J. Material Eng. & Perf. 9, 1 (2000) 103-109.

DOI: 10.1361/105994900770346358

[15] E. Buyukkaya, M. Cerit, Thermal analysis of a ceramic coating diesel engine piston using 3-D finite element method, Surf. Coat. Tech. 202 (2007) 398-402.

DOI: 10.1016/j.surfcoat.2007.06.006

[16] A.J. Helmisyah, S. Abdullah, M.J. Ghazali, Characterisation of thermal barrier coating on piston crown for compressed natural gas direct injection (CNGDI) engines, Asian Int. J. Sci. and Tech. in Prod. & Manu. Eng. 5(4) (2012) 73-77.

DOI: 10.4028/www.scientific.net/amm.52-54.1830

[17] A. Shamsudeen, Design and development of cylinder head for a four stroke direct injection automotive engine using compressed natural gas, MSc. Thesis, National Univ. of Malaysia, (2007).

[18] V. Esfahanian, A. Javaheri, M. Ghaffarpour, Thermal analysis of an SI engine piston using different combustion boundary condition treatments, Appl. Ther. Eng. 26 (2006) 277-287.

DOI: 10.1016/j.applthermaleng.2005.05.002
