Observation Frequency Selection Based on Dynamic and Electric Field Excitation Method for Advanced Detection in Coal Mine Roadway

Abstract:

The dynamic and electric field excitation method is a new advanced detection method. In this method, the observation frequency and of emission electrode must be reasonably selected according to the actual geological conditions of coal mine roadway to obtain the apparent frequency with adequate Induced Polarization (IP) information of geological anomalies and improve the measurement accuracy of the instrument. This paper completed the simulation of apparent frequency varying with the observation frequency and Cole-Cole model parameters with MATLAB software. The results show that the key to selecting the observation frequency mainly depends on the charge and discharge time constant .Then the paper analyzed the effect of the measured apparent frequency on the measurement accuracy. According to time constant values​​ of geological conditions in coal mine roadway, considering the efficiency and electromagnetic coupling effects on the measurement, it is best to select the observation frequency within a frequency range of 0.05~0.1Hz and the frequency ratio coefficient of 13 or 15. Now apparent IP effect is obtained.

• Periodical: Applied Mechanics and Materials (Volumes 675-677)
• Pages: 1301-1307
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.675-677.1301
• Online since: October 2014
• Authors: Zhi Min Liu*, Xi Gao Liu, Jin Tao Zhang, Wei Jie Zhang, Miao Wu
• Keywords: Apparent Frequency, Cole-Cole Model, Dynamic and Electric Field Excitation Method, Observation Frequency Selection

References

[1] W.J. Zhang, M.R. Hao and Y.B. Du: Discussion on new pilot detection of mine roadway baseddual frequency induced method, Coal Science and Technology, Vol. 38-3(2010), pp.73-75.

[2] W.J. Zhang, M.R. Hao and W.Z. Zhang: Study on realtime ahead detection technology for mining roadway based on double frequency induced method, The 2nd International Conference on MA CE(2011), pp.722-725.

DOI: 10.1109/mace.2011.5987028

[3] J.S. He: Dual frequency induced polarization method (Higher Education Press, Beijing, China 2006).

[4] W.H. Pelton, S.H. Ward and P.G. Hallof: Mineral discrimination and removal of inductive coupling with multifrequency IP, Geophysics, Vol. 43-3(1978), pp.588-609.

DOI: 10.1190/1.1440839

[5] K.S. Cole, R.H. Cole: Dispersion and absorption in dielectrics, Journal of Chemical Physics, 9(1941), p.341–353.

[6] Y.Z. Luo, Z.X. Wu: The application of frequency dependent factor in spectral induced polarization method, Chinese Journal of Geophysics. Vol. 35-4(1992), pp.490-500.

[7] B.Y. Ruan, R.L. Luo: A new recursive inversion method of the complex-resistivity Spectrum, Computing Techniques for Geophysical and Geochemical Exploration, Vol. 25-4(2003), pp.298-301.

[8] J. Xiang, N.B. Jones and D. Cheng: Direct inversion of the apparent complex-resistivity spectrum, Geophysics, Vol. 66-5(2000), pp.1399-1404.

DOI: 10.1190/1.1487085

[9] V.A. Komarov: Electrical Prospecting Using Induced Polarisation Method (Nedra Press, Leningrad, Russian 1980).

[10] J.M. Li: Geoelectric Field and Electrical Exploration (Geological Publishing House, Beijing, China. 2005).

[11] X.W. Cui, Z.X. He and X.J. Liu: Application of spectrum IP method in Dagang oilfield, Geophysical exploration in Oilfield, Vol. 39-11(2004), pp.101-105.
