Comparison Induced Voltage between 0.35 mm and 0.50 mm Thicknesses 3% SiFe (NG) with Different Frequency

Abstract:

– This paper presents the comparison induced voltage between 0.35 mm and 0.50 mm thicknesses 3% SiFe (NG) with different frequency which are 45 Hz, 50 Hz and 60 Hz by using Single Sheet Tester (SST). This experiment used to measure the search coil voltage L1N1 and L2N2 at two positions (1st position and 2nd position) and harmonic content. The analysis shows, at different frequency for both thicknesses, the value of search coil voltage L1N1 is higher than the search coil voltage L2N2 for both positions. It shows the easy direction is single sheet tester direction at the 1st position for 0.35 mm and 0.50 mm thickness with different frequency. For harmonic content, at 0.6 T with different frequency for both thicknesses, the 3rd order harmonic factor of 0.35 mm is lower than 0.50 mm thickness 3% SiFe (NG). It is because the higher losses can increase the harmonic of the materials. It means that harmonic is affected by ingredient and thicknesses in core material.
