Study on Seepage Control in Complicated Hydrogeological Conditions on the Right Bank of JinPing-I Hydropower Station

Abstract:

With consideration of the special hydrogeological conditions and layout characteristics of the hydraulic structures, the seepage control measures of dam abutment and underground powerhouse on the right bank of JinPing-I hydropower station is drawn up. Based on the three dimensional finite element analysis of seepage control with dry area virtual flow constant mesh analysis method, the rationality of the seepage control measures of dam abutment and underground powerhouse has been verified and the key factors affecting the effect of seepage have been compared. In combination with the curtain of dam abutment, the curtain of underground powerhouse is reasonable. The results showed that the steel liner of penstock after the curtain is necessary.

• Periodical: Applied Mechanics and Materials (Volume 686)
• Pages: 132-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.686.132
• Online since: October 2014
• Authors: Yan Wu*
• Keywords: 3D Finite Element, Hydraulic Structures, JinPing-I Hydropower Station, Seepage Control

References

[1] YING Heping, CHEN Xiangrong, ZHOU Hui, et al. Design of impermeable layer and discharge outlet system of large underground powerhouse. Rock and Soil Mechanics, 2008, 29 Supp. : 1~ 7. ( in Chinese).

[2] LIAO Huasheng, GAO Mingjun, LI Lianxia. Optimal simulation and analyzing to lower window, type seepage control scheme in left abutment of Shawan hydropower station [J]. Journal of Sichuan University ( Engineering Science Edition), 2005, (4): 1~ 6. ( in Chinese).

[3] WEI Jinbing, DENG Jianhui, GAO Chunyu, et al. Unsaturated seepage analysis and back analysis of permeability coefficient for XieTan land slide in Three Gorges Reservoir area [J]. Rock and Soil Mechanics, 2008, 29(8): 2262- 2266. ( in Chinese).

[4] LI Xiao, HU Yuefei, JIA Shuyuan. Study on the groundwater tracing test in JinPing Pusiluo ditch [J]. Journal of Geological Hazards and Environment Preservation, 2002, 13(4): 51- 55. ( in Chinese).

[5] MAO Changxi. Seepage Computation Analysis and Control [M]. Beijing: China Water Power Press, 2003. ( in Chinese).

[6] ZHAN Meili, SU Baoyu. Boundary treatment method for filtration control analysis of higher natural water table[J]. Design of Hydroelectric Power Station, 2001, 17(1): 1- 4. ( in Chinese).

[7] ZHAN Meili, SU Baoyu. A new method of close drainage hole simulation in the seepage control analysis [J]. Water Power, 2000, (4): 36- 39. ( in Chinese).

[8] ZHAN Meili, SU Baoyu. New method of simulating concentrated drain holes in seepage control analysis [J]. Journal of Hydrodynamics 1999, 11(3): 27- 35.
