Design Studies and Analysis of Single Phase 8S-12P Field Excitation Flux Switching Motor

Abstract:

This paper presents a new structure of field excitation flux switching motor (FEFSM) as an alternative candidate of non-permanent magnet (PM) machine. The rotor is consisted of only stack of iron and hence, it is reliable and appropriate for high speed operation. Initially, the coil arrangement tests are examined to validate the operating principle of the motor and to identify the zero rotor position. Furthermore, the profile of flux linkage, induced voltage, cogging torque, torque and power characteristics are observed based on 2D finite element analysis (FEA). Initial performances show that 8S-12P FEFSM produce torque and power of 8.79Nm and 1.5kW, respectively with low cogging torque and sinusoidal flux waveform. Further design refinement and optimization will be conducted to improve the performances of the motor.

You might also be interested in these eBooks

Advanced Research in Materials and Engineering Applications

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 695)

Pages:

601-604

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.695.601

Citation:

Cite this paper

Online since:

November 2014

Authors:

Zhafir Aizat Husin*, Erwan Sulaiman, Faisal Khan, Mohamed Mubin Aizat Mazlan, Mohd Fairoz Omar

Keywords:

DC Field Excitation Coil (DC-FEC), Field Excitation Flux Switching Motor (FEFSM), Hybrid Electric Vehicle (HEV)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. T. Chen, Z. Q. Zhu, S. Iwasaki, and R. Deodhar, Low cost flux-switching brushless AC machines, in: Vehicle Power and Propulsion Conf., IEEE, 2010, Lille, pp.1-6.

DOI: 10.1109/vppc.2010.5728984

Google Scholar

[2] C. Pollock, H. Pollock, R. Barron, J. R. Coles, D. Moule, A. Court, and R. Sutton, Flux-switching motors for automotive applications, IEEE Trans. Ind. Appl. 42 (2006) 1177–1184.

DOI: 10.1109/tia.2006.880842

Google Scholar

[3] J. F. Bangura, Design of high-power density and relatively high efficiency flux switching motor, IEEE Trans. Energy Convers. 21 (2006) 416–424.

DOI: 10.1109/tec.2006.874243

Google Scholar

[4] E. Sulaiman, M. F. M. Teridi, Z. A. Husin, M. Z. Ahmad and T. Kosaka, Performances Comparison of 24s-10p and 24s-14p Field Excitation Flux Switching Machine (FEFSM) With Single DC-Coil Polarity, Int. J. Energ. & Power Eng. Res. 1 (2013) 24-31.

DOI: 10.1109/peoco.2013.6564513

Google Scholar

[5] E. Sulaiman, T. Kosaka, N. Matsui, and M. Z. Ahmad, Design Studies on High Torque and High Power Density Hybrid Excitation Flux Switching Synchronous Motor for HEV Applications, in: Int. Power Eng. and Optimization Conference, IEEE, 2012, p.333.

DOI: 10.1109/peoco.2012.6230885

Google Scholar

[6] E. Sulaiman, M. F. M. Teridi, Z. A. Husin, M. Z. Ahmad and T. Kosaka, Investigation on Flux Characteristics of Field Excitation Flux Switching Machine With Single FEC Polarity, Proc. Tech. 11 (2013) 572-579.

DOI: 10.1016/j.protcy.2013.12.230

Google Scholar

[7] E. Sulaiman, T. Kosaka and N. Matsui, High power density design of 6-Slot–8-Pole hybrid excitation flux switching machine for hybrid electric vehicles, IEEE J. Trans. Magn. 47 (2011) 4453-4456.

DOI: 10.1109/tmag.2011.2140315

Google Scholar
