Nonlinear Response of Carbon-Carbon Laminated Panels to Random Acoustic Excitation under a Gradient Temperature Field

Abstract:

Future missions for aircraft will expose structures to severe thermal and acoustic loads. Efficient analysis methods for predicting nonlinear random response and fatigue life are urgently important. This paper presents a finite element model for analyzing nonlinear random dynamic behaviors of Carbon-Carbon composite panels under temperature gradients and Guassian excitations. The temperature distribution over the plate follows double sine curve. A finite element formulation combined with the equivalent linearization approach and normal mode method is established. The global system of equations is reduced to a set of nonlinear, coupled modal equations. Examples are given for an orthotropic C/C composite laminated panel at various combinations of temperatures gradients and sound pressure levels. Numerical results include RMS values of maximum deflection, time histories of deflection response and stress response, power spectrum densities, probability distribution functions and higher statistical moments. Numerical results verified all three types of panel motions for a simply supported orthotropic laminated plate: small-deflection random vibration about the initial equilibrium positions, snap-through motions between the two buckled positions, and nonlinear random response about new equilibrium positions after post-buckling. Numerical results will provide the important reference basis to aero engine structural integrity design and improving the structure dynamic strength and working life.

• Periodical: Applied Mechanics and Materials (Volume 696)
• Pages: 23-29
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.696.23
• Online since: November 2014
• Authors: Yun Dong Sha*, Hao Yuan Wang, Huan Yu
• Keywords: Carbon-Carbon Composite Laminated Panel, Guassian Excitations, Nonlinear Response, Temperature Gradients

References

[1] Mixson, J.S., Overview of Acoustic Fatigue Activities at NASA Langley Research Center, Third International Conference on Recent Advances in Structural Dynamics, University of Southampton, Wright-Patterson AFB, OH, AFWAL-TR-88-3034, pp.573-591, July (1988).

[2] Sha Yundong, Zhu Lin, Zhang Guozhi, Luan Xiaochi, Nonlinear Response and Fatigue Life of Thin Plates Subjected to Non-uniform Temperature distributions and Acoustic excitations. Applied Mechanics and Materials, Vols. 423-426 (2013) pp.1659-1669.

DOI: 10.4028/www.scientific.net/amm.423-426.1659

[3] Schneider, C.W., Acoustic Fatigue of Aircraft Structures at Elevated Temperatures, Wright-Patterson AFB, OH, AFFDL-TR-73-155, Part I, March (1974).

[4] Soovere, J., The Effect of Acoustic-Thermal Environment on Advanced Composite Fuselage Panels, AIAA/ASME/ASCE/AHS 24th Structures, Structural Dynamics and Materials Conference, Lake Tahoe, NV, May 1983, pp.466-472.

DOI: 10.2514/6.1983-955

[5] R. R. Istenes., S. A. Rizzi and H. F. Wolfe, Experimental Nonlinear Random Vibration Results of Thermally Buckled Composite Panels, Proceedings of 36th Structures, Structural Dynamics, and Materials Conference, New Orleans, LA, April (1995).

DOI: 10.2514/6.1995-1345

[6] Sha Yundong, Influences of Thermal Loads on Nonlinear Response of Thin-Walled Structures in Thermo-Acoustic Environment, Applied Mechanics and Materials, Vols. 105-107(2012)pp.220-226.

DOI: 10.4028/www.scientific.net/amm.105-107.220

[7] Sha Yundong, Gao Zhijun., Xu Fei. and Li Jiyong, Influence of Thermal Loading on the Dynamic Response of Thin-Walled Structure under Thermo-Acoustic Loading[C]. 2011, 2 876-881.

DOI: 10.4028/www.scientific.net/aef.2-3.876

[8] Sha Yundong, Wei Jing, Gao Zhijun, Zhong Haojie, Nonlinear Response with Snap-through and Fatigue Life Prediction for Panels to Thermo-acoustic Loadings, Journal of Vibration and Control, Vol. 20, n5, pp.679-697, April (2014).

DOI: 10.1177/1077546312463751

[9] Lee, J., Large-amplitude plate vibration in an elevated thermal environment, WL-TR-92-3049, (1992).

[10] Vaicaitis, R., Time domain approach for nonlinearresponse and sonic fatigue of NASP thermalprotection systems, , AIAA paper, 91-1 l77, lQ9l.

[11] Locke, J . E., Finite element large deflection random response of thermally buckled plates, J. Sound Vibn., 160(2), 1993, pp.301-312.

DOI: 10.1006/jsvi.1993.1025

[12] Robinson, J. H., Variational finite elementtensor formulation for the large deflection random vibration of composite plales, AIAA paper, 91-1240, (1991).

[13] Chen, C.C. -T., Yang, fI. T. Y., Geometrically I nonlinear random vibrations of laminated composite plate, Proc. 8th Int. Conf. on Comp. Mtls., IIonolulu, 111, 1991, p.34-B-1 Lo 34-B- 10.

[14] Sha Yundong, Jie Xiaobo and Zhu Lin, Nonlinear Response of C/C Composite laminated Panels with Temperature Gradients under Guassian Pressure Waves, Applied Mechanics and Materials, Vol. 470, pp.1062-1068, (2014).

DOI: 10.4028/www.scientific.net/amm.470.1062
