Design of Valve Parametric Variant Template Based on NX

Abstract:

The valve is an important control unit in all kinds of fluid conveying system, which has formed a series product. The design of the valve product follows the characteristic process, and there is a strong correlation between its components. Using knowledge engineering related theory and method, through mining and presentation about the field design knowledge and structure knowledge of the pressure valve, implements the pressure valve parametric variant design templates by using the top-down design and parametric design technology on the NX platform. It can greatly improve the design efficiency and quality through the rapid variant design of series of the valve with the template.

• Periodical: Applied Mechanics and Materials (Volume 697)
• Pages: 289-292
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.697.289
• Online since: November 2014
• Authors: Li Li Jiao*
• Keywords: NX, Parametric, Template, Top-Down, Valve, Variant
