Energy Harvesting and Regeneration from the Vibration of Suspension System

Abstract:

Two conceptual designs of energy regenerative suspension have been developed using commercial computer aided design (CAD) software. The designs are based on the available conventional suspension. They consist of basic magnet and coil for electrical energy regeneration and additional components for magnet support and coil winding circular holder. The selection of the design is based on weighted matrix which consists of reliability, cost, time consumption and weight. The score of the matrix is formulated based on relative weighted factor among the selections. All designs are fabricated using selected and available materials. The actual cost, time consumption and weight of the suspensions are compared with the theoretical weighted scores. Standard processes of cuttings, fittings and welding are performed in fabrication. Suitable magnet design is attached on the suspensions. The other moving part of the suspensions is attached by coil and coil holder. The suspensions are tested with various strokes and frequencies for feasibility studies and energy regeneration capability using suspension test rig. The evaluation of the suspensions is performed based on actual experimental results of voltage and power regenerated.

• Periodical: Applied Mechanics and Materials (Volume 699)
• Pages: 800-805
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.699.800
• Online since: November 2014
• Authors: Mohd Azman Abdullah*, Noreffendy Tamaldin, Muhammad Afiq Mohamad, Rahiman Salmi Rosdi, Mohd Noor Ikhwan Ramlan
• Keywords: Energy Harvesting, Energy Regeneration, Suspension System, Vehicle Vibration

References

[1] S. Roundy, 2005, On the effectiveness of vibration-based energy harvesting, Journal of Intelligent Material Systems and Structures, Vol. 16, pp.809-823.

DOI: 10.1177/1045389x05054042

[2] Zhang, Y., Huang, K., Yu, F., Gu, Y., and Li, D., 2007. Experimental Verification of Energy-regenerative Feasibility for an Automotive Electrical Suspension System,. Vehicular Electronics and Safety, pp.1-5, 13-15.

DOI: 10.1109/icves.2007.4456407

[3] Segal L., Xio-Peo L., Vehicular resistance to motion as influenced by road roughness, Australian Road Research, 12 (4) (1982), 211-222.

[4] Wendel G. R., Stecklein G. L., A regenerative active suspension system, SAE Technical Paper Series, 910659 (1991) 129-135.

DOI: 10.4271/910659

[5] Karnopp D., Permanent magnet linear motors used as vehicle mechanical dampers for vehicle suspensions, Journal of Vehicle System Dynamics, 18, (1989) 187-200.

DOI: 10.1080/00423118908968918

[6] Suda Y., Shiiba T., A new hybrid suspension system with active control and energy regeneration, Vehicle System Dynamics, supplement 25, (1996) 641-654.

DOI: 10.1080/00423119608969226

[7] Suda Y., Nakadai S., Nakano K., Study on the self powered active vibration control, Fourth International Conference on Motion and Vibration Control (1998) 91-96.

DOI: 10.1115/detc99/movic-8404

[8] Suda Y., Shiiba T., Hio K., Kawamoto Y., Condo T., Yamagata H., Study on electromagnetic damper for automobiles with nonlinear damping force characteristics, Vehicle System Dynamics, supplement 41, (2004) 637-646.

[9] Arsem H. B., Electric shock absorber, US. Patent Number 3559027 (1971).

[10] Murty B. V., Electric variable damping vehicle suspension, US. Patent Number 4815575 (1989).
