A Research on the Correction Method of Two-Dimensional Bar Code Distortion on Free Radius Cylindrical Surface

Abstract:

In order to solve the recognition problem caused by the distortion of two-dimensional bar code printed directly on the cylindrical units, a correction method has been put forward based on the combination of the information of space geometry calibrated in the camera and that of the image. Firstly, we should obtain the fixed parameters relating to the machine vision and then analyze how the two-dimensional bar code distorts on the cylindrical surface to find the correction method reversely. Since the cylindrical units vary from each other, it would be difficult to calibrate the radius of the units. Only by analyzing the perspective projection of the edge of the two-dimensional bar code on cylindrical surface and then founding the estimating function of radius can the parameters of radius be obtained from the image information. At last, the rationality of the algorithm is proved by experiments

• Periodical: Applied Mechanics and Materials (Volume 703)
• Pages: 177-181
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.703.177
• Online since: December 2014
• Authors: Cui Yan Wang*, Wei Wang
• Keywords: Cylindrical Unit, Distortion Correction, Target Recovery, Two-Dimensional Bar Code

References

[1] Si Guodong, Chen Zhong. Design and Implementation of Cylinder 2D Barcode Recognition Algorithm[J]. Modern Computer, 2013, (23): 25-27.

[2] Zhou Xiaowei. The Research of Two-Dimension Barcode Recognition Technology[ D]. Shanghai: Shanghai Jiao Tong University, (2007).

[3] Hu Donghong, Tan Hui, Chen Xinmeng. The Application of Radon Transform in 2D Barcode Image Recognition[J]. Wuhan University Journal: Natural Science Edition, 2005, 5 1(5): 584-588.

[4] Wang Hongping, Cao Guohua, LI Zhenhui, etc. Study of Distortion Correction of Image Based on BP Neural Network [J]. Journal of Changchun University of Science and Technology: Natural Science Edition, 2009, 32(4): 653-656.

[5] Tian Yongtao, Li Juan, Tian Linluai, etc. Concentric Circle-based Simple Method to Solve Image Distortion Center[J]. Computer Engineering, 2008, 24(21): 250-252.

[6] Xu Yongshun , Hu Xuezeng , Liang Zhaozheng, etc. Method for Correcting Geometric Distortion of Projected Image on Curved Curtain[P]. Chinese Patent: CN 1690770 A, 2005-11-2.

[7] Xu Fang, Liu Jinghong, Wang Xuan. Distortion Correction Method for CCD Image Based on Calibration [J]. Chinese Journa1 of Liquid Crystals and Displays, 2013, 28(4): 633-639.

DOI: 10.3788/yjyxs20132804.0633
