Optimal Design and Structural Precision Analysis for a Spherical Coordinate System 3D Scanner Guiding Device

Abstract:

Recently, automatic 3D scanning devices are commonly researched and developed for better productivity of the reverse engineering fields. In this paper, a 3D scanner utilizing a spherical coordinate system was designed and analyzed using FEM analysis. The system was designed for optimal performance, high precision, minimal deflection, and speed of data collection. FEM analysis allowed us to properly design the system to achieve these goals, with focus on the deflection of the cantilever arm. Results of the FEM analysis and figures showing the apparatus design are provided. Successive prototypes are shown to increase in overall performance and reliability through improved design and analysis.
