Air Compressor Piston Finite Element Analysis Based on ANSYS

Abstract:

The finite element analysis was carried out on the piston of WWD - 0.8/10 type air compressor under the action of mechanical load stress and deformation.Using three-dimensional modeling software Solidworks to establish a simplified geometric model of piston in air compressor ,Transform the model built in the three dimensional finite element analysis software into the finite element model for analysis,Determine the method of the piston by the mechanical load and boundary conditions,Completed the stress analysis and deformation analysis of the piston under the mechanical load ,The results of analysis of the piston design optimization has important reference value.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 15-17
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.15
• Online since: January 2015
• Authors: Xin Xiang Zhou*, Tian Shu Cong, Xing Long Lei, Feng Zhen Yang
• Keywords: 3D Modeling, Finite Element, Mechanical Load, Pistons
