An Optical-Triangulation-Based Method for Measurement of Blade Sections

Abstract:

Blades are an important part of aviation engine, its manufacturing compliance seriously affect the performance of the engine. Blades tend to be free-form surface modeling, which makes it extremely difficult to measurement. Since no probe radius compensation, high efficiency, non-contact optical measurement methods get more and more attention, but the inspection uncertainty of optical measurement is usually between 30um to 50um .To reduces the optical non-contact measurement uncertainty, this paper presents an Optical-triangulation-based method for measurement of blade sections. There is a data optimization process in the method, and this feature makes the proposed method can obtain better measurement results. At last, some experiments demonstrate the effectiveness of this method.
