The Modulation Index Optimization of Microwave Photonic Frequency Conversion Using Double-Sideband Suppressed-Carrier and Balance Detection

Abstract:

In this paper, on basis of DPMZM (Dual-Parallel Mach-Zehnder Modulator), an approach for microwave photonic frequency conversion using DSSC(double-sideband suppressed-carrier) and balance detection is demonstrated. DSSC and balance detection were used to realize high harmonic suppression, and achieve frequency conversion signal with high power and high spectrum purity. In addition, theoretical analysis and simulation results show that the optimal modulation index is m1=2, m2=1.81, and the harmonic suppression is greater than 30dB.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 475-478
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.475
• Online since: January 2015
• Authors: Wei Jiang*, Qing Gui Tan, Dong Liang, Xiao Jun Li, Zhong Bo Zhu
• Keywords: Balance Detection, DPMZM, DSSC, Frequency Conversion, Microwave Photonic

References

[1] Novak, D, The Evolution of Microwave photonics, IEEE Microwave Magazine, vol. 10, p.8, 10, 62, Jun. (2009).

[2] J. P. Yao, Microwave photonics, Journal of Lightwave Technology, vol. 27, pp.314-335, Feb. (2009).

[3] Tibor Berceli, P.R. Herczfeld, Microwave photonics-a historical perspective, IEEE transactions on microwave theory and techiques, vol. 58, pp.2992-3000, Nov. (2010).

DOI: 10.1109/tmtt.2010.2076932

[4] B. Benazet, M. Sotom, Microwave Photonics Cross-connect Repeater for Tele communication Satellities, Proc. of SPIE, vol. 6194, pp.619403-7, Apr. (2006).

DOI: 10.1117/12.662938

[5] B. Benazet, M. Sotom, Microwave Photonic Technologies for Flexible Satellite TelecomPayloads, ECOC, vol. 10, pp.1-4, Sep. (2009).

[6] Vincent J. Urick, John F. Diehl, etc, Wideband analog photonic links: some performance limits and considerations for multi-octave implementations,. Proc. of SPIE, vol. 8259, pp.825904-14, Jan. (2012).

DOI: 10.1117/12.912528

[7] Y. M. Zhang and S. L. Pan, Experimental demonstration of frequency-octupled millimeter-wave signal generation based on a dual-parallel Mach-Zehnder modulator, IEEE MTT-S International Microwave Workshop Series (IMWS), pp.1-4, Sep. (2012).

DOI: 10.1109/imws2.2012.6338202

[8] Guanghao zhu, Wei liu, and Harold R. Fetterman, A broadband linearized coherent analog Fiber-Optic link employing dual parallel Mach-Zehner modulator, Photonics Technology Letters, IEEE, vol. 21, pp.1627-1629, Nov. (2009).

DOI: 10.1109/lpt.2009.2031166

[9] S.R. O'Connor, M.L. Dennis, Optimal Biasing of a Self-Homodyne Optically Coherent RF Receiver, IEEE Photonics Journal, vol. 2, pp.1-7, Feb. (2010).

DOI: 10.1109/jphot.2009.2039931

[10] Vincent J. Urick , Meredith N. Hutchinson, etc, Suppression of even-order photodiode distortions via predistortion linearization with a bias-shifted Mach-Zehnder modulator, Optic Express vol. 21, pp.14368-14376, Jun. (2013).

DOI: 10.1364/oe.21.014368
