Design of Underwater Acoustic Vector Sensor and its Elastic Suspension Element

Abstract:

Acoustic vector sensor is a kind of inertial sensors. Different from pressure-sensing sensor, it can sense the angle of target under the water. Now most suspension elements are installed on the acoustic vector sensor later. This paper outlines an acoustic vector sensor which is encased in silicon rubber. In this paper, a new structure of acoustic vector sensor is present. The radial stiffness of silicon rubber spring is analyzed by using theory and simulation calculation based on the finite element software ANSYS. At last, the acoustic vector sensor is measured. The results show that the new structural design of acoustic vector sensor could reduce the adverse impact of suspending elastic suspension elements repeatedly and improve the reliability of acoustic vector sensor.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 569-572
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.569
• Online since: January 2015
• Authors: Shuang Liu*, Yu Lan, Qi Li
• Keywords: Accelerometer, Acoustic Vector Sensor, Rubber Spring

References

[1] AIP Conference Proceedings368, Acoustic Particle Velocity Sensors: Design, Performance, and Applications, M. J. Berliner and J. F. Lindberg, American Institute of Physics, (1995).

[2] C.B. Leslie, J. M. Kendall, and J. L. Jones. Hydrophone for measuring particle velocity[J], Journal of the Acoustic Society of American, 1956 (28). 711-715.

DOI: 10.1121/1.1908455

[3] Benjamin A. Cray. Acoustic vector sensor[P]. United States Patent No. 6370084. (2002).

[4] Richard F. Keltie. Analysis and design of an elastically coated acoustic velocity sensor[CD]. The 21st international congress on sound and vibration, beijing, (2014).

[5] Nathan kahikina Naluai. Acoustic intensity methods and their applications to vector sensor use and design[D]. The Pennsylvania state University, UMI. No. 3248376. (2006).

[6] Zhang Yinghui. Manual of Spring[M], China Machine Press, 2006. 440-447.

[7] Shuang Liu, Qi Li, and Yong Liu. Design of cylindrical acoustic vector sensor[CD]. The 21st international congress on sound and vibration, beijing, (2014).
