Fault Diagnosis of Large Rotors Based on Wavelet Packet Neural Network

Abstract:

Using wavelet packet neural network method which is consist of wavelet packet and BP neural network to diagnose large rotors by vibration signal .Firstly , according to the spectrum characteristic of large rotors’ common vibration fault ,using the improved wavelet packet method to compute the energy of the spectrum that can reflect the fault information .And then make the feature vector as the input to establish a model of improved wavelet packet neural network for fault diagnosis . Collect the data of five working conditions from the test bench , establish a improved wavelet packet neural network model, and then use the model to diagnose fault. The experimental results show that this method improves the accuracy obviously and calculate fast.

• Periodical: Applied Mechanics and Materials (Volume 722)
• Pages: 363-366
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.722.363
• Online since: December 2014
• Authors: You Juan Zheng*, Ping Liao, Cai Long Qin, Yu Li
• Keywords: BP Neural Network, Energy Spectrum, Fault Diagnosis, Vibration Signal, Wavelet Packet

References

[1] Bai Lei , Liang Ping . Kolmogorov entropy vibration faults diagnosis of steam turbine rotor based on wavelet packet filtering [J]. JOURNAL OF IBRATION AND SHOCK, 2008, 27(5): 148-153.

[2] Zhang Jun , Wang Jinping , Zhu Bo. Sianal Filtering and Feature Extraction Technology of Rotating Machinery Vibration Signal Process [J]. Journal of Nanjing Institute of Technology (Natural Science Edition) , 2009, 7(3): 14-21.

[3] Yang Yujing. Rearch of Fault Diagnosis of Rotating Machinery Vibration Based on Neural Network[D]. Beijing : North China Electric Power University, 2012: 10-11.

[4] Ran Jun . Filtering and pattern recognition Method of rotor fault signals [D]. Lanzhou : Lanzhou University of Technology , 2012: 23-26.

[5] Guo Liquan, Wang Keming. The extraction of areo-engine fault feature based on wavelet packet energy spectrum[J]. Journal of Shengyang Aerospace University, 2014, 31(1): 12-15.

[6] Sun Yankui . Wavelet analysis and its application [M]. Beijing : Machinery Industry Press, 2005: 63-66.

[7] Huang Qiang , Liu Yongchang , Ye Xiaoming. The Research on the extraction of vibration signal based on interval wavelet packet[J]. Journal of vehicle engine, 2003, 4(146): 49-51.

[8] Li bin, Wang Encheng . The detection of alumina clinker based on wavelet packet analysis and BP network [J]. Journal of Shangdong University of Technology (Natural Science Edition), 2013. 6: 40-43.

[9] Zeng Xianwei , Zhao Weiming , Sheng Juqing , Corresponding relationships between nodes of decomposition tree of wavelet packet and frequency bands of signal subspace[J]. ACTA SEISM OLOGICA SINICA , 2008, 30(1): 90-96.

DOI: 10.1007/s11589-008-0091-x

[10] Xian Pingfan , Zhagn Chagnshui . Artificial neural networks and simulated evolutionary computation [M]. Beijing : Tsinghua University Press , 2000. 55-60.

[11] Feisi science and Technology Research Center . The theory of wavelet analysis and MATLAB7 inplementation [M]. Publishing House of electronics industry , 2005: 343-346.
