FEA of Double Metal Composite Seamless Steel Tube with Cross-Rolling

Abstract:

The numerical simulation of the cross-rolling stainless steel/carbon steel double metal composite seamless steel tube process was conducted through the finite element analysis of the three-dimensional thermo-mechanical coupled elastic-plastic by applying the MSC.MARC software. Based on the numerical simulation, The character of stress, strain and temperature distribution parameters during the two roll cross-rolling were obtained by the finite element analysis, and acquired the section pass deformation figure. The distribution of the axial stress, circle stress and radial stress were drawn in the cross-rolling roll gap profile along the circle. The mechanism of tube cross-rolling process was explained according to the stress distribution. The results of the research can be applied to the design of the cross-rolling forming process.

• Periodical: Applied Mechanics and Materials (Volume 722)
• Pages: 64-68
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.722.64
• Online since: December 2014
• Authors: Xuan Gu*, Xu Ma, Duo Ye Jin
• Keywords: Cross-Rolling, Double Metal Composite Seamless Steel Tube, Finite Element Method (FEM), Numerical Simulation, Thermo-Mechanical Coupling

References

[1] Wang X K, Ye J D, Ma X, et al. Finite Element Simulation Analysis of Multi-Stands Three-Roller Cold Rolling Process for Double Metal Composite Seamless Steel Tube[J]. Applied Mechanics and Materials, 2014, 470: 197-204.

DOI: 10.4028/www.scientific.net/amm.470.197

[2] Yin Yuande, Li Shengdi. The 3-D finite element analysis of steel tube continuous rolling process with multi-stand pipe mill, [J]. heavy machinery, 2005. (4): 39-42.

[3] Zong Jiafu, Zhang Wenzhi, Xu Xiumei, et al. Finite element simulation of reversal cold rolling mill for asymmetrical clad strip, [J]. steel rolling, 2004. (6): 21-25.

[4] Xu Xiumei, Zhang Wenzhi, Zong Jiafu, et al. Investigation on extreme reduction in cold rolling of stainless steel/steel clad sheet based on FE simulation, [J]. heavy machinery, 2003. (6): 21-25.

[5] Haimiao Wu, Guiying Yao, Yanwei Zhang, et al. Research into Edge Drop of Cold Rolled Strip and Its Influencing Factors[C]. 2010 Second International Conference on Computer Modeling and Simulation, 2010, (48): 152-154.

DOI: 10.1109/iccms.2010.48

[6] Pei-feng Hao. The structure and function of computer control simulation system in cold mill[J]. Journal of Northeastern University: Natural Science, 2001, 22(6): 639-642.
