Shearing Property Study on PC Box-Girder Bridge with Corrugated Webs

Abstract:

PC box-girder bridge with corrugated webs is a new kind of bridge, which named by the thin steel webs replacing thick concrete webs. It is applied abroad in China recently, which attracts attention for its shearing property. Because of lacking relative design and construction code interiorly, the related data of Mi-Luo-Jiang bridge was used in the study with the software ANSYS 10.0. The shearing property and bucking stability of Mi-Luo-Jiang bridge were studied and a theory was verified: corrugated webs do not bear moment and axial force. Besides, the result that the decisive parameter of shearing property of Mi-Luo-Jiang bridge should be allowable shear stress is obtained. The other study had been done on buckling stability of box-girder bridge with different corrugated shapes, maintaining other parameters invariant. Finally, the optimal scope of lateral plane length is [0.2,0.4], and the optimal scope of folded angle is [20º,50º]. The parameters used in Mi-Luo-Jiang bridge is verified as the best value. This study is meaningful and the results can be applied in the design and construction of the same type bridge.

• Periodical: Applied Mechanics and Materials (Volume 724)
• Pages: 121-125
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.724.121
• Online since: January 2015
• Authors: Lan Xie, Guo Jing He*
• Keywords: Buckling Stability, Folded Angle, Lateral Plane, Shearing Property, Steel Corrugated Webs

References

[1] Qiang Xu, Shui Wan, etc: Design and Application of Box-girder Bridge with Corrugated Webs (China Communication Press, Beijing 2009), (in Chinese).

[2] Wanyong Zhu. Study on Design Theory and Method of Box-girder Bridge with Corrugated Webs [D]. 2004, Chang an University (in Chinese).

[3] Yiyan Chen: Design and Construction of Prestressed Box-girder Bridge with Corrugated Webs (China Communication Press, Beijing 2009), (in Chinese).

[4] Fumin Wang. Experimental Study on Box-girder Bridge with Corrugated Webs [D]. Nanjing: Southeast University, 1997 (in Chinese).

[5] Guojun Li. Static and Dynamic Characteristic Study on PC Box-girder Bridge with Corrugated Webs [D]. Southeast Jiaotong University, 2010 (in Chinese).

[6] Jian Wang etc. Design and Construction Study on PC Box-girder continuous Bridge with Corrugated Webs of Huanghe Bridge in Juancheng in Shandong Province [J]. Steel Bridge Branch of China Steel Structure Association, Academic annual Conference of Bridge Project of China Railway Committee，2010 (in Chinese).

DOI: 10.1061/40616(281)19

[7] Xinmin Wang: Numerical Analysis of Engineering Structures with ANSYS (China Communication Press, Beijing 2007), (in Chinese).

[8] John T. Easley. Buckling Formulas for Buckling Formulas for Corrugated Metal Shear Diaphragms. Joumal of the Structural Division，July. 1975: 1403-1417.

DOI: 10.1061/jsdeag.0004095

[9] M. Rosignoli. Prestressed concrete box girder bridge with folded steel plate webs. Structures and Buildings, 1992, 2, 134: 77-85.

DOI: 10.1680/istbu.1999.31255

[10] Allan B, Lius L. Shear Buckling of Trapezoidally Corrugated Girder Webs [R]. Report，Part 2, (1984).
