Driver Seat Differential Pneumatic System with Air Damping

Abstract:

The paper shows a possibility of the tuning mechanical system by means of two pneumatic springs in a differential configuration connected with a throttle valve. The springs are inserted into the lead mechanism and connected to its parts, and to its supporting platform. The vibrations, transferred from the kinematic excitation of the base, are intended to be minimized. The vibration isolation by means of pneumatic springs is available in many technical systems, e.g. in supports of heavy machinery as well as in systems characterized by the human interaction, such as driver seats, ambulance couchettes, etc. The pneumatic springs provide the option of adaption of the stiffness, and herewith the adaption of the natural frequency of the system according to the exciting frequency. In cases of application of the object vibration isolation, they can change the load characteristics in a relative large range. In the studied case of the differential spring configuration, the springs are connected with an air pipe to the throttle valve. The air being exchanged during the motion period comes through the valve, the cross-section of which determines the time delay of the pneumatic sub-system thus creating a hysteresis of load characteristic of the spring support. This brings an additional, controllable damping to such a system that is profitable in most vibration isolation cases.

• Periodical: Applied Mechanics and Materials (Volume 732)
• Pages: 191-194
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.732.191
• Online since: February 2015
• Authors: Ondrej Kohl, Lubomír Pešík, Antonin Skarolek
• Keywords: Air Damping, Vibroisolation

References

[1] D. J. Whitehouse, Handbook of surface and nanometrology, Second Edition, CRC Press, Boca Raton, (2011).

[2] V. Zeman, Z. Hlaváč, Vibration of Mechanical Systems, Západočeská univerzita v Plzni, Plzeň, 2010. (in Czech).

[3] L. Pešík, A. Skarolek, Heat Transfer Effects on Vibration Isolation Differential Pneumatic System, in: Transactions of the Universities of Košice, Research reports from the Universities of Košice, 3rd edition, Technická univerzita v Košiciach, Košice, 2012, pp.109-114.

DOI: 10.33542/poe2021-0036-3

[4] L. Pešík, A. Skarolek, Tuning of Vibration Isolation Differential Pneumatic System by Means of Trottle Valve, in: Transactions of the Universities of Košice, Research reports from the Universities of Košice, 2nd edition, Technická univerzita v Košiciach, Košice, 2011, pp.191-196.

DOI: 10.33542/poe2021-0036-3

[5] H. Dresig, F. Holzweißig, Maschinendynamik, 8. Auflage, Springer Verlag, Berlin, (2008).

[6] C.M. Harris, Shock and Vibration Handbook, Fifth edition, McGraw-Hill, NewYork, (2005).
