Experimental and Numerical Investigation of Response of Sandwich Composite Beam Subjected to Low-Velocity Impact

Abstract:

This paper deals with the progressive failure analysis of sandwich composite beam loaded with transversely low-velocity impact. A user defined material model was used for modeling of the non-linear orthotropic elastic behavior of composite skin. The non-linear behavior of foam core was modeled using Low-Density Foam material model. The numerical model was validated using performed experiment and the results in terms of deflection and contact force time dependencies are mutually compared.

• Periodical: Applied Mechanics and Materials (Volume 732)
• Pages: 239-246
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.732.239
• Online since: February 2015
• Authors: Tomáš Mandys*, Vladislav Laš, Tomáš Kroupa, Robert Zemčík
• Keywords: Damage, Fiber-Glass Fabric, Foam Core, Low Velocity Impact (LVI), Sandwich Composite Panel

References

[1] M. Meo, A.J. Morris, R. Vignjevic, G. Marengo, Numerical simulations of low-velocity impact on an aircraft sandwich panel, Composite Structures 62 (2003) 353-360.

DOI: 10.1016/j.compstruct.2003.09.035

[2] J. Wang, A.M. Waas, H. Wang, Experimental and numerical study on the low-velocity impact behavior of foam-core sandwich panels, Composite Structures 96 (2013) 298-311.

DOI: 10.1016/j.compstruct.2012.09.002

[3] P. Sadílek, R. Zemčík, J. Bartošek, T. Mandys, Active structural health monitoring of composite plates and sandwiches, Applied and Computational Mechanics 7 (2013) 183-192.

[4] A. Mostafa, K. Shankar, E.V. Morozov, Effect of shear keys diameter on the shear performance of composite sandwich panel with PVC and PU foam core: FE study, Composite Structures 102 (2013) 90-100.

DOI: 10.1016/j.compstruct.2013.03.003

[5] T. Kroupa, J. Krystek, H. Srbová, P. Janda, Plastic behavior in shear and degradation of shear modulus of textile composite materials with simple plane wave, in: T. Návrat, V. Fuis, L. Houfek, M. Vlk (Eds. ), Proceedings of 49th International Scientific Conference on Experimental Stress Analysis 2011, Brno University of Technology, Znojmo, 2011, pp.169-176.

[6] C. Menna, A. Zinno, D. Asprone, A. Prota, Numerical assessment of the impact behavior of honeycomb sandwich structures, Composite Structures 106 (2013) 326-339.

DOI: 10.1016/j.compstruct.2013.06.010

[7] A. Matzenmiller, J. Lubliner, R.L. Taylor, A constitutive model for anisotropic damage in fiber-composites, Mechanics of Materials 20 (1995) 125-152.

DOI: 10.1016/0167-6636(94)00053-0

[8] V.I. Rizov, Non-linear indentation behavior of foam core sandwich composite materials / A 2D approach, Computational Materials Science 35 (2006) 107-115.

DOI: 10.1016/j.commatsci.2005.02.009

[9] T. Kroupa, R. Zemčík, J. Klepáček, Temperature dependence of parameters of non-linear stress-strain relationship for carbon epoxy composites, Materiali and Technologije 43 (2009) 69-72.

[10] V. Laš, R. Zemčík, Progressive damage of unidirectional composite panel, Journal of Composite Materials 42 (2008) 22-44.

DOI: 10.1177/0021998307086187

[11] C.F. Yen, Ballistic Impact modeling of composite materials, in: 7th International LS-Dyna User's Conference, Dearborn, Michigan, (2006).

[12] R. Zemčík, V. Laš, T. Kroupa, H. Purš, Identification of material characteristics of sandwich panels, Bulletin of Applied Mechanics 26 (2011) 26-30.

[13] Abaqus 6. 11 Documentation, Dassault Systèmes Simulia Corp., (2011).
