Grid Connected Photovoltaic Simulation System Based on TMS320F28027

Abstract:

This device uses TMS320F28027 as the control core. It realizes functions of MPPT, frequency and phase synchronization, under voltage and over current protection, under voltage recovery and so on. It displays its main information on the LCD screen, providing a good man-machine interface. The topology of the main circuit is full bridge inverter which is controlled by doubled frequency SPWM modulation. MPPT is realized with constant input voltage method. Phase tracking is realized with software PLL. The performance of this device is satisfying. The relative voltage error is less than 0.7% when doing MPPT. The relative frequency error is less than 0.09%. The phase error is approximately 2°. The THD of the output voltage is less than 2%. The action voltage of the under voltage protection is 25.02V. The action current of the over current protection is 15.0A. The efficiency of this device is over 84%.

• Periodical: Applied Mechanics and Materials (Volume 733)
• Pages: 691-694
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.733.691
• Online since: February 2015
• Authors: Xie Deng*
• Keywords: C2000, Doubled Frequency SPWM, MPPT, Photovoltaic Grid Connected Inverter, PLL

References

[1] Xu Dehong, Ma Hao, Wang Yousheng. Power electronic technology. Science press. 2007, 08.

[2] He Xiaoting. The design of electronic system. Zhejiang University press, 2004, 08.

[3] Raymond A. Mack, Jr., Xie Yunxiang. Switching power supply entry. People's Posts and Telecommunications Press, 2007, 09.

[4] Zheng Jialong, Wang Xiaohai, Zhang yuan. Integrated electronic technology foundation course. Higher education press, 2002, 07.

[5] Yu Yangwei, the day was, Xie Wentao, Lv Zhengyu. LC filter based on PWM inverter. Mechanical and electrical engineering. 2007, 06.

[6] Xu Daofei. Online DSP digital control technology based on UPS. Master degree thesis of Zhejiang University. 2003, 02.
