The Design and Characteristic Analysis of the Steering System of Balanced Rocker Wheeled Chassis

Abstract:

According to the particularity of balanced rocker wheeled chassis, a four wheel independent steering system was designed. The chassis of the two degree of freedom model was established, the proportional feedback control of yawing angular velocity and front wheel Angle-yawing angular velocity was simulated, the chassis steering performance under the two classic control methods was analyzed, then the dynamics of mechanical model was established in ADAMS software, the steering performance under different speed was simulated. At last, compared with two simulation results, it was proved that the steering system has good handling stability.

• Periodical: Applied Mechanics and Materials (Volume 743)
• Pages: 3-10
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.743.3
• Online since: March 2015
• Authors: Xiao Lin Xie*, Feng Gao
• Keywords: Adams, Balanced Rocker Wheeled Chassis, Steering System

References

[1] Gao, F., A kind of engineering machinery balance radial chassis walking device, China Patent 1188962. (2013).

[2] H. Inoue and F. Sugasawa. Comparison of Feedforward and Feedback Control or 4WS, Vehicle System Dynamics. (22)1993，p.425~436.

DOI: 10.1080/00423119308969041

[3] Brach R. Vehicle dynamics model for simulation on a macrocomputer. Int, J of Vehicle Design. (10)1992: 25~28.

[4] Wang, M., Zhao,J., Tao, M.H., Optimal design of a car steering mechanim. Automotive Engineering. 1995, 17(6): 360~366.

[5] Higuchi A, Saitoh Y. Optimal control of four wheel steering vehicle. Vehicle System Dynamics, 1993, 22(5~6): 397~410.

DOI: 10.1080/00423119308969039

[6] Zhang, F. N., Cui, X. Z., Yuan, Y. L., Model and kinematics analysis of engineering vehicles. Mechanical Research & Application. (2009).

[7] Shiang Lung Koo, Fanping Bu, Han Shue Tan, Vehicle steering control under the impact of low-speed tire characteristics, Minnesota: Proceedings of the 2006 American Control Conference, 2006: 4676~4681.

DOI: 10.1109/acc.2006.1657459

[8] GUO, K.H., Vehicle manipulation dynamics, Jilin Science Technology Press, Changchun, ISBN：7-5384-0859-2: 206-221, (1991).

[9] Jin, L. Q., Song, C. X., Peng, Y.H., Theory for optimization design of steer wheel alignment based on return ability and handiness. Transactions of the Chinese Society for Agricultural Machinery,: 20~23, Jul. (2006).

[10] Hou, Y., Hu, Y., Hu, D., and Li, C., Synthesis of Multi-Axle Steering System of Heavy Duty Vehicle Based on Probability of Steering Angle, SAE Technical Paper 2000-01-3434, 2000, doi: 10. 4271/2000-01-3434.

DOI: 10.4271/2000-01-3434

[11] Miller Gerald. Robert Reed, Fred Wheeler, Optimum Ackerman for improved steering Axle Tire Wear on Trucks. SAE paper: 107-128, doi: 10. 4271/912693.

DOI: 10.4271/912693

[12] Liu, Y. H., Ji, X. W., Simulation of cavitation's in rotary valve of hydraulic power steering gear. Science In China Press: 56~58, Feb. (2009).

[13] Sven K., Johannes V. N., Modeling and Control of a Steer-By-Wire Vehicle. Vehicle system dynamics Supplement (S0042-3114): 114~142, Sep. (1998).

DOI: 10.1080/00423119808969556

[14] Chen, W. W., Shi, P. C., Gao, L. X., Modeling and Control Strategy Simulation for Automobile EPS System Based on ADAMS and Matlab, Transactions of the Chinese Society for Agricultural Machinery: 22~34, Feb. (2007).

[15] Bao, X. Q., Chen, J., Wang, J. N., The technology of date interfaces between CAD and CAE software. Machinery Design & Manufacture: 82~84, Aug. (2008).
