Shear Capacity Research on Transversely Reinforced Concrete Beams

Abstract:

Inner transverse prestressed bars were used to enhance the shear capacity of concrete beams in this paper, which can be used in transformer beams to reduce the sectional size. Two transversely prestressed one ordinary concrete beams were tested and calculated by finite element method, and the following conclusions can be drawn: (a)The shear capacity of transversely prestressed concrete beam increase rapidly with the increase of the prestressing force level, which means that prestressing force level has a great influence on the shear capacity of transversely prestressed concrete beam. (b) The transverse prestressing bars can efficiently enhance the anti-crack performance of the reinforced concrete beams.

• Periodical: Applied Mechanics and Materials (Volumes 744-746)
• Pages: 283-287
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.744-746.283
• Online since: March 2015
• Authors: Can Liu*
• Keywords: Reinforced Concrete Beam, Shear Capacity, Transversely Prestressed Bars

References

[1] K. Y. Zhang, L. J. Liu and Y. Liao: Research on the vertical prestress design of long-span PC continue beam bridge. Journal of Highway and transportation research and development. Vol. 21 (2004), p.45. (In Chinese).

[2] H. Huang, X. B. Tang, K. Y. Zhang and M. S. Xiang: Numerical simulation on vertical prestressed effect and experimental studies on prestressed loss. Journal of Wuhan University of Technology. Vol. 31 (2007), p.922. (In Chinese).

[3] L. Y. Chen, W. M. Wu and Y. Chen: Research on new methods for vertical prestress setting of box beam webs. Technology of Highway and Transport. Vol. 6 (2007), p.48. (In Chinese).

[4] Y. Shi, C. S. Tang, J. M. Xuan and Y. Z. Lu: Analysis of vertical prestress applied to webs of concrete box girder. Bridge construction. Vol. 1 (2006), p.8. (In Chinese).

[5] Z. Z. Zhao and A. K. H. Kwan: Nonlinear finite element analysis of deep reinforced concrete coupling beams. Engineering Structures. Vol. 26 (2004), p.13.

DOI: 10.1016/j.engstruct.2003.08.014

[6] P. Bhatt and M. A. Kader: Prediction of shear strength of reinforced concrete beams by nonlinear finite element analysis. Computers and structures. Vol. 68 (1998), p.139.

DOI: 10.1016/s0045-7949(98)00034-0

[7] H. T. Hu, F. M. Lin and Y. Y. Jan: Nonlinear finite element analysis of reinforced concrete beams strengthened by fiber-reinforced plastics. Composite Structures. Vol. 63 (2004), p.271.

DOI: 10.1016/s0263-8223(03)00174-0

[8] B. B. Adhikary and M. Hiroshi: Shear strengthening of RC beams with web-bonded continuous steel plates. Construction & Building Materials. Vol. 20 (2006), p.296.

DOI: 10.1016/j.conbuildmat.2005.01.026

[9] People's Republic of China Ministry of Construction: Steel Structure Design Specification GB50017-2003(China Building Industry Press, China 2002). (In Chinese).
