Finite Element Analysis of Bolted Flanged Joints Subjected to External Loads

Abstract:

Since external loads affect the sealing performance of bolted flanged joints, this paper calculated external loads of bolted flanged joints by using CAESAR II software and evaluated the effects of external loads on the sealing performance from the viewpoint of changes in contact gasket stress and flange rotation by using ANSYS software. The FE results showed that the contact gasket stress decreases a lot at the tension side and increases a little at the compression side. The paper also evaluated the stress distribution in bolted flanged joints subjected to external loads. The results suggested that the flange rotation and the overall stress increased compared with that of flange without external loads. External loads can induce unexpected leakage and strength failure of the bolted flanged joints during operation.

• Periodical: Applied Mechanics and Materials (Volume 750)
• Pages: 324-329
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.750.324
• Online since: April 2015
• Authors: He Hui Wang, Ya Juan Feng*, Wen Min Zhu, Zhi Ming Zhang
• Keywords: Bolted Flanged Joints, External Loads, Fe, Leakage

References

[1] M. Matsumoto, T. Sawa, T. Nishida, FEM stress analysis and sealing performance evaluation in pipe flange connections with gaskets subjected to external bending moments,J. Transactions of the Japan Society of Mechanical Engineers, Part A. 69(5)(2003).

DOI: 10.1299/kikaia.69.823

[2] M. Matsumoto, T. Sawa, FEM stress analysis and sealing performance evaluation in pipe flange connections with spiral wound gaskets subjected to external bending moments (case where internal fluid is liquid),J. Transactions of the Japan Society of Mechanical Engineers, Part A. 71(4)(2005).

DOI: 10.1115/pvp2008-61168

[3] T. Sawa, T. Yoshio, S. Koji, O. Yuya, D. Hayato, Effects of Scattered Bolt Preload on the Sealing Performance of Pipe Flange Connection With Gaskets Under External Bending Moment and Internal Pressure,J. ASME 2012 Pressure Vessels and Piping Conference, Volume 2: Computer Technology and Bolted Joints(2012).

DOI: 10.1115/pvp2012-78411

[4] T. Sawa, N. Ogata, T. Nishida, Stress Analysis and Determination of Bolt Preload in Pipe Flange Connections with Gaskets under Internal Pressure. Journal of Pressure Vessel Technology, J. 124(4)(2002): 385-396.

DOI: 10.1115/1.1511736

[5] Y. Takagi, H. Torii, T. Sawa,Y. Omiya, Effect of External Bending Moment on the Sealing Performance of Pipe Flange Connection,J. ASME Pressure Vessels and Piping Conference: Volume 3, (2010).

DOI: 10.1115/pvp2010-25180

[6] JB4732-2005 Steel Pressure Vessels—Analysis and Design Standard [S]. Beijing: State Bureau of Technical Supervision, 2005. (In Chinese).

[7] ASME. Boiler and pressure vessel code, section VIII, Division I. New York: American Society of Mechanical Engineers, (2010).
