Analysis of Vibration Testing for the Structure with Bolted Flange Joints

Abstract:

The test was simulated for the thin-walled cylinder structure of aeroengine stator casing. Based on the software of LMS-TEST, the experiment of the structure with bolted flange joints was successfully completed for the vibration test analysis and the paper completed the testing under different pre-tightening force. Through the analysis of the measured data, the corresponding spectrum and difference value curve were obtained, the research results showed that the nonlinear characteristics of the bolted flange joint was significant influence on the dynamic responses of the structure, the various nonlinear vibration phenomenon and the signal asymmetry were obvious under different pre-tightening force, which was closely related to the state of the bolted pre-tightening force. By the information of the spectrum and acceleration difference curve, the extent of the bolt tightness can be determined, which can provide relevant reference information for the diagnosis of bolted joint status in the aeroengine stator casing.

• Periodical: Applied Mechanics and Materials (Volume 751)
• Pages: 205-210
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.751.205
• Online since: April 2015
• Authors: Ming Ming Liu*, Qing Gang Zhai, Hong Shi
• Keywords: Bolted Flange Joints, Nonlinear Characteristics, Spectrum Analysis, Thin-Walled Cylinder Structure, Vibration Test

References

[1] WuYuan-Dong. Vibration analysis of aero-engine considering connecting stiffness and damping [D]. Nanjing: NanjingUniversity of aeronautics and astronautics, (2010).

[2] Sun Dan, LI Wan-you, LV Bing-lin. Review of Structural Modeling Methods for Bolted Joints[J]. Noise and Vibration Control. 2012. 32(6): 8-12.

[3] ZangChaoping, Ewins D. J. Model Validation for Structural Dynamics in the Aero-Engine Design Process[J]. Frontiers of Energy and Power Engineering in China. 2009. 3(4): 480-488.

DOI: 10.1007/s11708-009-0043-8

[4] Li Ting-ting, Zhao Deng-feng, Ma Guo-lu. Analysis ofVibration Testing Data ofFlange Connection Structures[J]. Noise and Vibration Control. 2010(01): 132-134.

[5] Gao Xu, ZengGuo-ying. Analysis ofVibration Simulation ofBolts-Flange Connection Structure[J]. Noise and Vibration Control. 2010(03): 38-40.

[6] ZhaiXue. Studyon the Interface of Bolt Connection on the DynamicCharacteristic of Aircraft engine case [D]. Shenyang: Shenyang University of aeronautics and astronautics, (2012).

[7] Bai Yan. Study on vibration characteristics of casing connecting structure based on technology [D]. Shenyang: Shenyang University of aeronautics and astronautics, (2013).

[8] Boeswald M., Link M., Meyer S. Experimental and Analytical Investigations of Non-Linear Cylindrical Casing Joints Using Base Excitation Testing[M]. 2003: 3-6.
