Study on Wheel-Rail Coupled Vibration of Metro with Co-Simulation of Finite Element Analysis and Multi-Body Dynamics Simulation

Abstract:

Based on the multi-body dynamics theory and modal-reduction analysis, finite element method and multi-body dynamics were combined to establish the flexible track model. The rigid-flexible coupled dynamics model can reflect the features of coupled vibration accurately. When the flexibility of the rail, damping and stiffness of support layers under the rail are taken into consideration, the whole track structure acted as a buffer while wheel and rail is interacting with each other. Compared with rigid track model, the wheel-rail vibration is less in the flexible track model. The proposed method in this paper is simple and effective, which makes the calculation of vehicle-track dynamic response more convenient and quick.

• Periodical: Applied Mechanics and Materials (Volumes 752-753)
• Pages: 636-641
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.752-753.636
• Online since: April 2015
• Authors: Wen Jing Sun, Dao Gong, Jin Song Zhou*
• Keywords: Finite Element Analysis (FEA), Flexible Track Model, Multi-Body Dynamics Theory, Wheel-Rail Coupled Dynamics

References

[1] W. Zhai, K. Wang, C. Cai, Fundamentals of vehicle–track coupled dynamics, Vehicle Syst. Dynam. 47 (11) (2009) 1349-1376.

DOI: 10.1080/00423110802621561

[2] W. Sun, J. Zhou, D. Thompson et al, Vertical random vibration analysis of vehicle-track coupled system using Green's function method, Vehicle Syst. Dynam. 52 (3) (2014) 362-389.

DOI: 10.1080/00423114.2014.884227

[3] Y. Zhao, S. Gao, T. Huang et. al, Dynamic Model Reduction of Complex Structures, J. Fudan university (Natural Science), 44 (3) (2005) 355-362.

[4] L. Baeza, A. Rodaa and J.C.O. Nielsen, Railway vehicle/track interaction analysis using a modal substructuring approach, J. Sound Vib. 293 (2006) 112-124.

DOI: 10.1016/j.jsv.2005.09.006

[5] J. Zhou, Railway vehicle vibration and control, Beijing, China Railway Press, (2012).
