Finite Element Analysis of Automobile Suspension Control Arm

Abstract:

In order to improve the reliability and stability of the automobile suspension system, the important parts of automobile suspension control arm is studied. Reverse engineering technology is applied to reverse modeling according to the characteristics of complicated suspension control arm shape. At the same time, the automobile suspension control arm is analyzed under load condition to ensure that the automobile suspension control arm is safe in the process of driving. The control arm meshing and strength analysis are completed by ANSYS analysis software. Finally, ANSYS fatigue analysis module is used to verify that the automobile suspension control arm can meet the requirement of fatigue strength.

• Periodical: Applied Mechanics and Materials (Volumes 752-753)
• Pages: 859-863
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.752-753.859
• Online since: April 2015
• Authors: Hai Bo Zhang*, Rui Jun Zhang, Ying Chang
• Keywords: ANSYS, Automobile Suspension Arm, Finite Element Analysis (FEA), Reverse Engineering

References

[1] Fa Su, Lanyu Yang, Shuguang Niu. Present Situation and Development Trend of Automobile Engine Connecting Rod Materials [J]. Automotive technology and Materials, 2007 (7) : 7-9.

[2] Xianyu Liu. Finite Element Analysis of the Automobile Engine Connecting Rod [J]. Mechanical and Electrical Equipment, 2005, 24 (3) : 9-11.

[3] Cuicui Jiang, WenBin. Automobile Suspension Control Arm [J]. Modern Components, 2008 (2) : 90-92.

[4] Minfeng Huang, Yingchun Jiang. Fatigue Life Analysis of Automobile Component Based on FEM [J]. Mechanical Research and Application, 2008, 21 (2) : 57-59.

[5] Kang Huang, Rongde Yang. Fatigue Analysis of Car Lateral Stabilizer Bar Base on ANSYA [J]. Journal of Mechanical Design, 2008 (17) : 69-71.

[6] Bing Li, Zhengjia He, Xuefeng Chen. ANSYS Workbench Design, Simulation and Optimization [M]. Beijing: Tsinghua University Press, (2008).

[7] YueJin Shang, Hong Wang. Finite Element Principles and ANSYS Practice [M]. Beijing: Tsinghua University Press, (2012).

[8] Rui Zhang, Jianhua Li . Realization of ProE Curved Face Modeling and the MeshCast Grid Division [J]. Foundry Technology, 2007 (10) : 1353-1355.

[9] Kang Huang, Rongde Yang. Stress Analysis of Stress Concentrated Location of Connecting Rod Through Analyse the Boundary Elements [J]. Modular Machine Tool and Automatic Manufacturing Technique, 1997 (1) : 20 -22.

[10] Tiancun Le. The Finite Element Analysis and Structure Optimization of Sedan Car Suspension Control Arm [D]. Changchun: JiLin University, (2009).

[11] Yuan Gao, Jianwen Fan, Guangxing Tan. Control for Chaos in Automobile Suspension System Based on Back Stepping Design Adaptive Sliding Mode Controller [J]. China Mechanical Engineering, 2013, 24 (11) : 1531-1536.
