Computer Assisted Selection of Servomotor Driving System for Linear Motion NC Axis Experimental Stand

Abstract:

The paper presents the works performed by the authors in the field of structural and functional optimization numerically controlled (NC) axes. The study includes two computing applications developed by second author of the paper in a PhD thesis related on NC axes’ structural and functional optimization. The first computing application is used for calculating the total reflected inertia of a linear motion NC axis (total inertial loads' reducing on the driving motor's shaft level). The second computing application is used for both preliminary selection of the driving servomotor (by checking first the accomplishment of the kinematic criterion) and a secondary selection of the electric motor (by checking in a second stage the accomplishment of the static and dynamic criterion). By mean of both software applications optimal matching of servomotor driving system with available NC axis mechanical structure may be determined. The analyzed linear motion NC axis is part of an experimental stand (existing in the MMS department from EMTS faculty), that supplementary to the driving servomotor, includes a belt drive transmission, a ball screw - bearings assembly and a driven element guided by ball rail system.

• Periodical: Applied Mechanics and Materials (Volume 762)
• Pages: 61-66
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.762.61
• Online since: May 2015
• Authors: Florin Adrian Nicolescu*, Georgia Cezara Avram, Andrei Mario Ivan, Adrian Theodor Mantea
• Keywords: Computing Applications, Experimental Stand, NC Axis, Selection, Servomotor

References

[1] Avram G. - C., Cercetări privind optimizarea structural – funcţională a axelor comandate numeric ale RI, în vederea creşterii performanţelor acestora (Research on structural and functional optimization of IR's numerically controlled axes in order to increase their performances), University POLITEHNICA of Bucharest, Bucharest, PhD. Thesis, pp.123-135 (2014).

[2] Information on http: /www. fagorautomation. ch/_downloads/man_fxm_fkm_motors. pdf (FAGOR AUTOMATION, MOTOR FXM / FKM Installation manual Ref. 1301, FAGOR, 2013).

[3] Information on http: /www. fagorautomation. com/downloads/manuales/en/man_dds_hard. pdf FAGOR AUTOMATION, DRIVE DDS Hardware manual, Ref. 1307 (2013).

[4] A. Nicolescu, C. Avram, M. Ivan, Optimal servomotor selection algorithm for industrial robots and machine tools NC axis, Proceedings in Manufacturing Systems, Volume 9, Issue 2, (2014), p.105−114.

[5] Information on http: /www. jp. nsk. com/app01/en/ctrg/index. cgi?rm=pdfView&pno=e3162 Catalog NSK – Precision Machine Components / NSK Linear Guides, Ball Screws, Monocarriers, Japan (2002).

[6] Information on http: /www. schaeffler. com/remotemedien/media/_shared_media/08_media_ library/01_publications/ schaeffler_2/catalogue_1/downloads_6/prg_us_us. pdf.

[7] Project Relansin 1971/19. 09. 2004, Stand complex pentru testarea și încercarea șuruburilor cu bile (Complex stand for testing ball screws assembly), project director prof. phd. eng. Nicolae Predincea.

[8] Parpală R. C. - Virtual design of a machine tool feed drive system / U.P.B. Scientific. Bulletin, Series D, Vol. 71, Issue. 4 (2009).
