Analysis of Vertical Rolling Force with GM Yield Criterion and Anti-Symmetric Parabola Dog-Bone Shapes

Abstract:

Vertical rolling is a vital method for width control in rolling, which has its own deformation characteristic. During the processing, plastic deformation does not go further into center of slab, only in edge where the deformation will be occurred. In this paper, an anti-symmetric parabola is creatively used to describe dog-bone shape and innovatively applied to establish a knematically admissible continuous velocity field for vertical rolling. Based on this field, an analytical form of total deformation power is obtained which is a function of reduction geometric parameters, and friction factor m, as well as parameter of A which is to be determined. With minimization of total power results in rolling forces and torque calculated by this new method is obtained. Copper and aluminum experiments conducted by S.-E.Lundberg are used to verified the results calculated by formula in present paper and compared with those by Lundberg and Duckjoongs’ models. The error is no more than 13%, (average error 7%).

• Periodical: Applied Mechanics and Materials (Volume 775)
• Pages: 34-38
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.775.34
• Online since: July 2015
• Authors: Hong Yu Wang*, De Wen Zhao, Dian Hua Zhang
• Keywords: Analytical Solution, Anti-Symmetric Parabola Dog-Bone Shape, Gm Yield Criterion, Minimization, Vertical Rolling Force

References

[1] G. Takeo, T. Takubo, K. Ohara, MAEY, T. ARAI. Internal force control for rolling operation of polygonal prism. ROBIO, (2009), 586-591.

DOI: 10.1109/robio.2009.5420608

[2] C. H. Moon, Y. Lee. Methodology for draft schedule design of plate rolling process with peening effect considered. Proc. of the Inst. of Mech. Eng. Part B, B9, 223, (2009), 1159-1169.

DOI: 10.1243/09544054jem1417

[3] P. K. Plotnikov. Friction-force model for a ball with predis placement of rolling on a rough surface. DOKL. PHYS., 55, (2010), 287 -291.

DOI: 10.1134/s1028335810060108

[4] S. -E. Lundberg, T. Gustafsson. Roll Force, Torque, Lever Arm Cofficient, and Strain Distribution in Edge Rolling.J. Mater. Eng. Perform, 2, (1993), 873-888.

DOI: 10.1007/bf02645688

[5] D. Yun, D. Lee,J. Kim and S. Hwang. A New Model for the Prediction of the Dog-bone Shape in Steel Mills . ISIJ int., 52, (2012), 1109-1117.

DOI: 10.2355/isijinternational.52.1109

[6] S.H. Zhang, X.N. Wang, B.N. Song and D.W. Zhao. Limit analysis based on GM criterion for defect-free pipe elbow under internal pressure. Int. J. Mech. Sci. 78, (2014) 91-96.

DOI: 10.1016/j.ijmecsci.2013.10.022
