Development of Rectangular Loop Microstrip Antenna Integrated with Light Emitting Diode (LED) for Wi-Fi Application

Abstract:

This paper presents the development of a rectangular loop microstrip patch antenna integrated with Light Emitting Diode (LED) for Wifi application. The objective to integrate with LED is to have dual applications in a device which illumination and also wireless communication. The antenna was designed at a frequency of 2.4 GHz and Computer Simulation Technology (CST) was used to optimized the position of LED within the rectangular loop antenna. The performances of the antenna in terms of return loss, gain and radiation pattern was verified through simulation by using Microwave Studio in CST. The antenna was fabricated on FR4 substrate with permittivity, ε_{r =} 4.5 and thickness, h = 1.6mm. The LED integrated within the patch was conducted parallel and was measured by Vector Network Analyser (VNA) to demonstrate the capacity and potential of the antenna. The antennas are reasonably well matched at their corresponding frequency of operations between simulation and experiment.

• Periodical: Applied Mechanics and Materials (Volume 781)
• Pages: 116-119
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.781.116
• Online since: August 2015
• Authors: S. Subahir, M.T. Ali, Nurulazlina A. Ramli, Siti Nurhidayah Kamaruddin, A.H. Awang, Muhammad Ramlee Kamarudin
• Keywords: CST, FR4 Substrate, Light Emitting Diode (LED), Rectangular Microstrip Patch Antenna, WIFI

References

[1] Chang Yong Rhee, Jea Hak Kim, Woo Jae Jung, Taejoon Park, Byungje Lee, Frequency-Reconfigurable Antenna for Broadband Airborne Applications, IEEE Antennas And Wireless Propagation Letters, Vol. 13, (2014).

DOI: 10.1109/lawp.2014.2301036

[2] Duxian Lu, Brian Gaucher, A New Multiband Antenna for WLAN/ Cellular Applications, Vehicular Technology Conference (2004), pp.243-246.

DOI: 10.1109/vetecf.2004.1399979

[3] M.T. Ali, T. A. Rahman, M.R. Kamarudin, R. Sauleau, A Reconfigurable Planar Antenna Array (RPAA) with Back Lobe Reduction, International Workshop on Antenna Technology (IWAT2010), 1-3Mac2010, pp.1-4.

DOI: 10.1109/iwat.2010.5464784

[4] H. M Zali, M. T Ali, I. Pasya, N. A Halili, H. Ja'afar, M. Hilmi Design of a Cylindrical parabolic reflector on Monopole Plasma Antenna, in 2013 IEEE International RF and Microwave Conference (RFM2013), (2013).

DOI: 10.1109/rfm.2013.6757281

[5] V. Kumar, M. Mishra, and N. K. Joshi, Study Of A Fluorescent Tube As Plasma Antenna, Progress In Electromagnetics Research Letters, Vol. 24, 17-26, (2011).

DOI: 10.2528/pierl11030201

[6] I. R. James, and P. S. Hall, Handbook of microstrip antennas, IEE Electromagnetic Waves Series 28, VOL. 1, (1989).
