Characterization and Formulation of Microstrip-Slot Impedance with Different Thickness and Relative Permittivity

Abstract:

This paper presents the characterization of a microstrip-slot line in terms of its impedance and dimension. The characterization is made by referring to the analysis of different relative permittivity and thicknesses of substrates, which conducted by using CST Microwave Studio. Based on the characterization with the use of completing square curve fitting method, new formulated equations are proposed for microstrip-slot line. These formulated equations are suitable for thin substrate with low relative permittivity. The characterization is made based on the substrates with the selected thickness of 0.508 mm, 0.762 mm and 1.542 mm, for relative permittivity of 4.5 (TMM4), 3.38 (RO 4003C) and 2.94 (RT 6002).

• Periodical: Applied Mechanics and Materials (Volume 781)
• Pages: 53-56
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.781.53
• Online since: August 2015
• Authors: Khairul Huda Yusof, Norhudah Seman*, Mohd Haizal Jamaluddin, D.N.A. Zaidel
• Keywords: Completing Square Curve Method, Microstrip-Slot, Power Divider, Relative Permittivity, Substrate

References

[1] D. Pozar, Microwave Engineering, third ed., Wiley, New York, (2005).

[2] Z. Zhang, Y-C. Jiao, S-F. Cao and F-S. Zhang, Design of a Broadband Three-way Power Divider Using Modified Microstrip-Slotline, IEEE CIE International Conference Radar (Radar), 2011, pp.1205-1207.

DOI: 10.1109/cie-radar.2011.6159771

[3] M. E. Bialkowski and Y. Wang, Wideband Microstrip 1800 Hybrid Utilizing Ground Slots, IEEE Microwave and Wireless Components Letters, 20(2010) 9.

DOI: 10.1109/lmwc.2010.2056677

[4] L. Xiao, H. Peng, T. Yang, and J. Dong, Power Divider Based on Stepped-Impedance Slotline, Progress In Electromagnetics Research C, 2014, pp.147-154.

DOI: 10.2528/pierc14042903

[5] L. Xiao, H. Peng, and T. Yang, The Design of a Novel Compact Ultra-wideband (UWB) Power Divider, Progress In Electromagnetics Research Letters, 2014, pp.43-46.

DOI: 10.2528/pierl13111205

[6] N. K. Das., Generalized Multiport Reciprocity Analysis of Surface-to-surface Transitions Between Multiple Printed Transmission Lines, IEEE Trans., 1993, pp.1164-1177.

DOI: 10.1109/22.238542

[7] R. Garg, I. Bahl and M. Bozzi, Microstrip Lines and Slotlines, third ed., Artech House, (2013).

[8] R. Janaswamy and D. H. Schaubert, Characteristic Impedance of a Wide Slotline on Low-Permittivity Substrates, IEEE Transaction on Microwave Theory and Technique, 34 (1986) 8.

DOI: 10.1109/tmtt.1986.1133465

[9] T. Itoh., Spectral Domain Immitance Approach for Dispersion Characteristics of Generalized Printed Transmission Lines, IEEE Trans, 1980, pp.733-736.

DOI: 10.1109/tmtt.1980.1130158
