Fabrication of Multi-Scale Grid Patterns as Deformation Carriers in Optical Methods

Abstract:

Multi-scale grid is an essential deformation carrier in optical methods for multi-scale deformation measurement. In this study, several new-type multi-scale grids were designed and fabricated by electron beam lithography. Each pattern includes several periodically distributed dots with the same spacing but different sizes. As a consequence, the grayscale of the whole grid pattern periodically changes. The peak parts of the grayscale generate a secondary grid, i.e., the large-scale grid. The ratio of the large-scale grid pitch to the small-scale grid pitch can be easily adjusted according to the requirement. The natural integration between the small-scale grid and the large-scale grid works well in eliminating the mutual disturbance between the different-scale grids. Besides, this type of grid has a very high success rate in fabrication owing to the small differences in size between the big dots and the small dots. The proposed multi-scale grid pattern is expected to serve as the deformation carrier in moiré methods and geometric phase analysis for multi-scale deformation measurement.

• Periodical: Applied Mechanics and Materials (Volume 782)
• Pages: 271-277
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.782.271
• Online since: August 2015
• Authors: Qing Hua Wang*, Shi En Ri, Hiroshi Tsuda, Satoshi Kishimoto, Yoshihisa Tanaka, Yutaka Kagawa
• Keywords: Deformation, Electron Beam Lithography, Grid, Micron, Multi-Scale, Submicron

References

[1] R. Weller, B.M. Shepherd, Displacement measurement by mechanical interferometry, Proceedings of the Society for Experimental Stress Analysis 6, 1 (1948) 35-38.

[2] P. Ifju, B. Han, Recent applications of moiré interferometry, Experimental Mechanics 50 (2010) 1129-1147.

DOI: 10.1007/s11340-010-9404-9

[3] M.J. Hÿtch, J.L. Putaux, J.M. Pénisson, Measurement of the displacement field of dislocations to 0. 03 Å by electron microscopy, Nature 423 (2003) 270-273.

DOI: 10.1038/nature01638

[4] Q.H. Wang, S. Kishimoto, H.M. Xie, et al., In-situ high temperature creep deformation of micro structure with metal film wire on flexible membrane using geometric phase analysis, Microelectronics Reliability 53, 4 (2013) 652-657.

DOI: 10.1016/j.microrel.2012.10.016

[5] Y. Tanaka, K. Naito, S. Kishimoto, et al., Development of a pattern to measure multiscale deformation and strain distribution via in situ FE-SEM observations, Nanotechnology 22 (2011) 115704.

DOI: 10.1088/0957-4484/22/11/115704

[6] J.C. Wyant, Double frequency grating lateral shear interferometer, Applied Optics 12, 9 (1973) 2057-(2060).

DOI: 10.1364/ao.12.002057

[7] A. Assa, J. Politch, A.A. Betser, Slope and curvature measurement by a double-frequency-grating shearing interferometer, Experimental Mechanics 19, 4 (1979) 129-137.

DOI: 10.1007/bf02324225

[8] H.M. Xie, Y.J. Li, H. Du, et al., The technique for fabricating submicron moiré grating using FIB milling, Advanced Materials Research 47-50 (2008) 710-713.

DOI: 10.4028/www.scientific.net/amr.47-50.710

[9] E.H. Anderson, C.M. Horwitz, H.I. Smith, Holographic lithography with thick photoresist, Applied Physics Letters 43, 9 (1983) 874-875.

DOI: 10.1063/1.94533

[10] S. Kishimoto, M. Egashira, N. Shinya, Microcreep deformation measurements by a moiré method using electron beam lithography and electron beam scan, Optical Engineering 32, 3 (1993): 522-526.

DOI: 10.1117/12.61046

[11] Q.H. Wang, S. Kishimoto, H. Tsuda, Formation of three-way scanning electron microscope moiré on micro/nanostructures, The Scientific World Journal 2014 (2014) 281954.

DOI: 10.1155/2014/281954

[12] Y.J. Li, H.M. Xie, Q.H. Wang, et al., Fabrication technique of deformation carriers (gratings and speckle patterns) with FIB for microscale/nanoscale deformation measurement[M]/FIB Nanostructures, Lecture Notes in Nanoscale Science and Technology, Springer International Publishing, 2013, Vol. 20, pp.267-298.

DOI: 10.1007/978-3-319-02874-3_10

[13] Q.H. Wang, H.M. Xie, Z. W. Liu, et al., Residual stress assessment of interconnects by slot milling with FIB and geometric phase analysis, Opt. Laser. Eng., 48 (2010) 1113-1118.

DOI: 10.1016/j.optlaseng.2009.12.006

[14] Q.H. Wang, S. Kishimoto, Y. Tanaka, et al., Micro/submicro grating fabrication on metals for deformation measurement based on ultraviolet nanoimprint lithography, Optics and Lasers in Engineering 51, 7 (2013) 944-948.

DOI: 10.1016/j.optlaseng.2013.02.021

[15] M.J. Tang, H.M. Xie, J.G. Zhu, et al., Study of moiré grating fabrication on metal samples using nanoimprint lithography, Optics Express 20, 3 (2012) 2942-2955.

DOI: 10.1364/oe.20.002942

[16] S. Kishimoto, Y. Tanaka, T. Tomimatsu, Fabrication of micromodel grid for various moiré methods by femtosecond laser exposure, Optics Letters 34, 1 (2009) 112-114.

DOI: 10.1364/ol.34.000112
