Passing-Cloud Effects of Solar Photovoltaic System on Distribution Network Voltages

Abstract:

The introduction of Feed-in Tariff (FiT) scheme has prompted an increasing number of grid-connected Photovoltaic (PV) systems installations in Malaysia. As a consequence, the network issues related to the PV systems integration need to be properly addressed. This includes the effect of solar irradiance intermittency which is caused by the passing-clouds. In this regard, this paper investigates the effect of passing-cloud on a standard IEEE 4 node test feeder, focusing on short term voltage drop analysis. Actual five-minute interval PV generation data in Melaka, Malaysia was used in the analysis. The network was analyzed by using the well-known OpenDSS tool. The network voltage impact of different PV penetration levels were investigated on both sunny and cloudy days. The results show that temporal voltage drop could occur on the network when there is a sudden drop of PV generation driven by passing-cloud. The percentage of voltage drop recorded was observed to be proportionate to the increment of PV penetration levels.

• Periodical: Applied Mechanics and Materials (Volume 785)
• Pages: 551-555
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.785.551
• Online since: August 2015
• Authors: Cheiw Yun Lau, Chin Kim Gan*, Chin Ho Tie, Kyairul Azmi Baharin, Mohamad Fani Sulaima
• Keywords: Cloud, Distribution Network, Photovoltaic
