Design and Implementation of Perturb and Observe (P&O) MPPT Technique for Negative Output Super-Lift Luo Converter

Abstract:

TThe growing energy demand in recent years has led to increased use of renewable energy resources. Among all renewable energy sources, the photovoltaic (PV) power generation acts as a green source which is free from greenhouse emissions to provide feasible solution to the increasing energy demand. However the non-linear nature of the solar module, their low-efficiency and high capital cost is being the major hindrance to the penetration and reach of the solar photovoltaic systems. To overcome this non-linearity, this paper presents the implementation of Negative Output Super-Lift Luo converter (NOSLC) with the solar panel. NOSLC is a type of super-lift converter in which the negative output voltage increases in geometric progression. Along with this, to track the maximum power from the PV cell, a technique named Perturb and Observe (P&O) Maximum Power Point Tracking (MPPT) is employed. This proposed system is modelled and simulated using MATLAB/Simulink and validated with the theoretical calculations.

• Periodical: Applied Mechanics and Materials (Volume 787)
• Pages: 888-892
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.787.888
• Online since: August 2015
• Authors: P. Dhivya, V. Chamundeeswari, R. Seyezhai
• Keywords: Maximum Power Point Tracking, Negative Output Super-Lift Luo Converter (NOSLC), Observe, Perturb, Photovolatic

References

[1] N. Pandiarajan, Ranganath Muthu, Mathematical Modeling of Photovoltaic Module with Simulink, International Conference on Electrical Energy Systems. (2011) 3-5.

DOI: 10.1109/icees.2011.5725339

[2] S. Nema, R.K. Nema, and G. Agnihotri, Matlab / Simulink based study of Photovoltaic Cells / modules / array and their Experimental Verification, International Journal of Energy and Environment. 1 (3) (2010) 487-500.

[3] S. Sheik Mohammed, Modelling and Simulation of Photovoltaic Module using MATLAB/Simulink, International Journal of Chemical and Environmental Engineering. 2 (5) (2011) 350-355.

[4] Fang Lin Luo, Hong Ye, Advanced DC-DC converters, CRC Press, September 29, (2003).

[5] Indu V. R , V. Chamundeeswari, Design and Implementation of Maximum Power Point Tracking for Super Lift Converter, International Journal for Research and Development in Engineering. (2014) 012-016.

[6] Bidyadhar Subudhi, and Raseswari Pradhan, A Comparative Study on Maximum Power Point Tracking Techniques for Photovoltaic Power Systems, IEEE Transactions on Sustainable Energy. 4 (1) (2013) 88-89.

DOI: 10.1109/tste.2012.2202294

[7] Ahmed M. Atallah, Almoataz Y. Abdelaziz, and Raihan S. Jumaah, Implementation of Perturb and Observe MPPT of PV system with Direct Control Method using Buck and Buck-Boost Converters, Emerging Trends in Electrical, Electronics & Instrumentation Engineering: An international Journal. 1(1) (2014).

DOI: 10.17148/ijireeice.2015.3311

[8] M.S. Sivagamasundari, Dr.P. Melba Mary, V.K. Velvizhi, Maximum Power Point Tracking for Photovoltaic System by Perturb and Observe Method Using Buck Boost Converter, International Journal of Advanced Research in Electrical, Electronics and Instrumentation Engineering. 2 (6) (2013).

DOI: 10.1109/icpeices.2018.8897408

[9] Azadeh Safari and Saad Mekhilef, Simulation and Hardware Implementation of Incremental Conductance MPPT with Direct Control Method using Cuk Converter, IEEE Transactions on industrial electronics. 58 (4) (2011) 1154 – 1161.

DOI: 10.1109/tie.2010.2048834
