ANSYS Analysis on Thermal Structure of Bionic Brake Discs

Abstract:

The failure of brake performance, which is caused by thermal recession under the emergency brake, results in traffic accident frequently. Based on excellent wear-resisting properties of locust’s non-smooth surface structure, bionic brake disc with special surface micro-structure was designed. According to the thermal analysis theory, transient temperature field analysis of the bionic brake disc during the braking process under different initial velocity was analyzed. The results showed that bionic brake disc has excellent heat dissipation ability, which is beneficial to improve the brake performance. The non-smooth surface can store air and dissipate heat, thus reducing the thermal fatigue and thermal wear caused by temperature rise. This research provides a theoretical basis for designing bionic brake discs with excellent heat dissipation performance.

• Periodical: Applied Mechanics and Materials (Volumes 789-790)
• Pages: 430-435
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.789-790.430
• Online since: September 2015
• Authors: Li Xin Wang, Ya Yan Gao, Li Qiang Peng, Li Gang Zhai
• Keywords: Bionic Design, Brake Disc, Engineering Bionics, Heat Dispersion, Simulation Analysis, Thermal Structure Coupled Analysis

References

[1] H.X. Chen, P. Zhu, Research and discussion on mechanism of brake heat fading caused by friction materials, J. Tractor &Farm Transporter. 33 (2006) 34-36.

[2] H.L. Shan, The effect of grooved surface texture on friction noise, D. Chengdu: Southwest Jiaotong University, (2012).

[3] J.M. Huang, C.H. Gao, X.S. Tang, Numerical modeling and analysis of the thermal-structure coupling of the disc brake, J. Chinese Journal of Mechanical Engineering. 44 (2008) 145-151.

DOI: 10.3901/jme.2008.02.145

[4] W.J. Zhao, T. Wu, Y. H Xu, Thermal field analysis of automobile brake disc based on ANSYS, J. Journal of Xihua University · Natural Science. 31 (2012) 31-34.

[5] L.Q. Ren, Q. Cong, J. Tong, Research of non-smooth surface basic characteristics in the interface adhesion, J. Transactions of the Chinese Society of Agricultural Engineering. 8 (1992) 16-22.

[6] Y.H. Sun, K. Gao, L.J. Zhang, High drilling efficiency and wear-resistant mechanism of coupling bionics impregnated diamond bit, J. Journal of Jilin University (Earth Science Edition). 42 (2012) 220-225.

[7] L.C. Dong, Z.W. Han, Y. Lv, The wear-resisting performance of ring-piece with pit bionic form, J. Journal of Jilin University (Engineering and Technology Edition). 41 (2011) 1659-1663.

[8] Y. F Chen, Modeling and simulation research for disc brake thermal and thermoelastic analysis, D. Beijing: Tsinghua University, (2011).

[9] D.Y. Zhao, Research on dissipation and friction-wear performance of automobile brake disc, D. Liaoning: Dalian University of Technology, (2013).

[10] X.Z. Zhang, W. Huang, Q.G. Liu, Heat transfer, third ed., Beijing, China, (2011).

[11] X. Yang, Z.H. Zhang, J.T. Wang, Computer simulation of bionic brake disc surfaces temperature and stress, J. Chinese Journal of Mechanical Engineering. 48 (2012) 121-127.

DOI: 10.3901/jme.2012.12.121
