The Impact of Different Direct-Driving Motor Design on Swivel Spindle Head

Abstract:

Swivel spindle head is a key component used in gantry type five-axis machine tool of high performance and is of great importance in its application and design. Nowadays, more and more components are manufactured by high precision CNC machine tools, such as components of spaceflight, renewable energy and automobile, etc. Therefore, high precision machine tools of multiple axes are more and more urgently demanded, while dual axis rotary head is one of the most important components for a multi-axis machine tool. Hence, it will be a key to develop dual axis spindle head that meets high precision needs. The study explores the highly responsive direct-driving motor able to drive the spindle head to rotate with multi-driving rotary technology. The dual-driving motor rotates via multi-driving units, generates torsion that magnifies and eliminates its clearance, and then drives the spindle head to rotate. Results of the test show that the completed machine tool can meet the standards of dual axis rotary head with high precision in, no matter, speed, distance, positional accuracy, repeated accuracy or maximum torque, etc.

• Periodical: Applied Mechanics and Materials (Volumes 789-790)
• Pages: 791-794
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.789-790.791
• Online since: September 2015
• Authors: Shao Hsien Chen*, Chin Mou Hsu, Kuo Lin Chiu, Chu Peng Chan
• Keywords: Multi-Driving, Rotary Head, Toque Motor

References

[1] M. F. Hsien, Y. C. Lai, A. Horng and M. C. Tsai, An Efficient Approach for Cogging Torque Analysis of Motors with Three-Dimensional Flux Distribution, IEEE Transactions on Magnetics, Vol. 42, No. 10, pp.3464-3466, (2006).

DOI: 10.1109/tmag.2006.879090

[2] Hull, Murakami, Application of bulk high-temperature Superconductors, Proceeding of the EEE, Vol. 92, No. 10, pp.1705-1718, (2004).

[3] Cochrane, N. M., Pal, S. K., Direct drive high energy permanent magnet brushless DC motor with an integrated driver for a novel 30000 RPM atomizer, IEEE Conference Publication, n 468, p pp.133-136, (1999).

DOI: 10.1049/cp:19991004

[4] C. C. Hwang, S. S. Wu and S. B. John, Magnetic Field Analysis of a Permanent Magnet DC Motor, " Proceedings of the 11th Conference on Magnetism & Magnetic Technologies, , Taoyuan, Taiwan Proceedings of the 11th Conference on Magnetism & Magnetic Technologies, p.395, July (1996).

[5] Shibata, Tsuchida, Imai, High torque induction motor with rotating magnets in the rotor, Electrical Engineering in Japan, v117, n 3, pp.102-109, Sep (1996).

DOI: 10.1002/eej.4391170309

[6] Sino Steel Corporation, Characteristic curve of electromagnetic steel sheet, (2011).

[7] G.R. Slemon, Electrical Machines for Variable-Frequency Drives, Proceedings of IEEE, Vol. 82, No. 8, August 1994, pp.1123-1139.

DOI: 10.1109/5.301681

[8] Hsu Chin-mou, Lin Ching-yuan, Chang En-sheng, Chung Shih-yen, Swivel Spindle Head with Gear Device Driven by Multiple Torque motors, United States Patent US7909550 (B1) ― 2011-03-22.

[9] Siemens, SIMODRIVE 1FW6 Built-in Torque Motors Configuration Manual, 02. 06 Edition.

[10] Yang Shijin, Optimal Design of Torque Motors for Machine Tools & Development of Optimal Waveform Control, Master thesis, National Taiwan University, p.39~65, (2007).
