Development of Calculation Methodology of Thermal Equivalent Circuit’s Parameters for Predicting Temperature of High Voltage Cable Lines 110 - 500 kV

Abstract:

This paper is concerned with the development of techniques to the calculation of the thermal equivalent circuit parameters for the high-voltage cable line laid in the ground. The topology of the scheme was developed in author’s previous publication. This article discusses the parameters of the circuit which simulate the environment of the cable line. Calculation techniques of these parameters are described for cables laid in a plane and a trefoil pattern. The proposed scheme allows one to predict heating of cables on the day ahead in order to prevent thermal degradation of the insulation.

• Periodical: Applied Mechanics and Materials (Volume 792)
• Pages: 272-279
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.792.272
• Online since: September 2015
• Authors: Evgeny Zaytsev
• Keywords: Heat Capacity, High Voltage Cable Line, Temperature, Thermal Equivalent Circuit, Thermal Resistance

References

[1] Kuljit Singh, Dan Watley, Cable Monitoring Solution - Predict with Certainty, Cabos'11 - Second Seminar on Undergrounding of Electric Distribution Networks, Maceió, Brazil, (2011).

[2] V.V. Belyakov, A.V. Malyshev, N.V. Krivocheev, Wolfgang K. Marschner, Monitoring of power cable lines with adaptation to the environmental conditions in real time, ELECTRO, №5 (2008), pp.38-40.

[3] IEC Calculation of the cyclic and emergency current rating of cables - Part 2: Cyclic rating of cables greater than 18/30 (36) kV and emergency ratings for cables of all voltages. International Electrotecnical Commission Standard 60853-2, July, (1989).

DOI: 10.3403/02652417

[4] E. Zaytsev, V. Lebedev, Development of the Thermal Equivalent Circuit for Evaluating the Capacity of High Voltage Cables in Real Time, Applied Mechanics and Materials, Vol. 698, pp.586-591, Trans Tech Publications, Switzerland, (2015).

DOI: 10.4028/www.scientific.net/amm.698.586

[5] A.A. Bubenchikov, Calculation of the temperature and electric power losses in the self-supporting insulated wires overhead lines of electric power systems, (dissertation abstract), Omsk, 2012, Vol. 20.

[6] V.D. Lebedev, E.S. Zaytsev, Smart Monitoring System of capacity and overheat protection of high voltage cable lines with XLPE insulation, XXII Intern. Scient. and Pract. Conf. «Relay protection and automation of electric power systems 2014», Moscow, 2014, pp.292-298.

[7] G.V. Greshnyakov, G.G. Kovalev, The numerical method of the analysis of high-voltage cable system load capacity, KABEL-news, №3, 2013, pp.32-37.

[8] F.C. Van Wormer, An Improved Approximate Technique for Calculating Cable Temperature Transients, Trans. Amer. Inst. Elect. Engrs, Vol. 74, Pt. 3, 1955, pp.277-280.
