Design Approach for Roll Forming of Profiles with Integrated Electrical Conductors

Abstract:

In metal forming a trend is observed towards increasing the performance of products by means of functional integration. One approach being pursued is the integration of electronic components. Multifunctional profiles with electrical conductors can transmit data and energy in addition to the mechanical function. They can be produced efficiently by roll forming. During the roll forming of multifunctional profiles wrinkles and cracks in the conductors may occur in the area of the contact of the rollers due to the contact normal stresses. In this paper, a design approach for multifunctional profiles preventing these failures in the tool contact area is presented and discussed on the basis of experimental and numerical investigations.

• Periodical: Applied Mechanics and Materials (Volume 794)
• Pages: 112-119
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.794.112
• Online since: October 2015
• Authors: Alexander Duschka*, Peter Groche
• Keywords: Forming, Polymer-Metal-Composite, Production

References

[1] M. Schwane, C. Dahnke, M. Haase, N. B. Khalifa, A. E. Tekkaya, Composite Hot Extrusion of Functional Elements, Advanced Materials Research Vol. 1018 (2014), 223-228.

DOI: 10.4028/www.scientific.net/amr.1018.223

[2] M. Brenneis, P. Groche, Integration of Piezoceramic Tube under Prestress into a Load Carrying Structure, Advanced Materials Research Vols. 966-967 (2014), 651-658.

DOI: 10.4028/www.scientific.net/amr.966-967.651

[3] K. Mori, N. Bay, L. Fratini, F. Micari, A.E. Tekkaya, Joining by plastic deformation, CIRP Ann. Manuf. Technol. 62 2 (2013) 673-694.

DOI: 10.1016/j.cirp.2013.05.004

[4] A. Schubert, V. Wittstock, S.F. Jahn, B. Müller, M. Müller: Joining by forming of piezoceramic macro-fiber arrays within micro-structured surfaces of aluminum sheets, Prod. Eng. Res. Devel. 1 11 (2013).

DOI: 10.1007/s11740-013-0498-7

[5] W.G. Drossel, S. Hensel, M. Nestler, L. Lachmann, A. Schubert, M. Müller, B. Müller, Experimental and numerical study on shaping of aluminum sheets with integrated piezoceramics fibers, J. Mater. Process. Technol. 214 2 (2014) 217-228.

DOI: 10.1016/j.jmatprotec.2013.08.011

[6] P. Groche, M. Ibis, C. Hatzfeld, A. Stöckigt, C. Gerlitzky, Economic production of load-bearing sheet metal parts with printed strain gages by combining forming and screen printing, International Journal of Material Forming, Springer (2014).

DOI: 10.1007/s12289-014-1165-z

[7] K. N. Bogojaw1enskij, A. Neubauer, V. W. Ris, Technologie der Fertigung von Leichtbauprofilen, VEB Deutscher Verlag für Grundstoffindustrie, Leipzig (1979).

[8] G. -T. Halmos, Roll Forming Handbook, Taylor & Francis Group, LLC (2006).

[9] P. Groche, C. Müller, Merkblatt 180 – Walzprofilieren von Flacherzeugnissen aus Stahl. Düsseldorf: Stahl-Informations-Zentrum (2013).

[10] D. Bhattacharyya, P. D. Smith, C. H. Yee, I. F. Collins: The Prediction of Deformation Length in Cold Roll-Forming, Auckland (1983).

[11] P. Groche, M. Ibis, W. Schmitt, C. Ludwig, Leichtbauprodukte mit hoher Funktionsintegration, Tagungsband Autometform, Freiberg (2010).

[12] P. Groche, A. Duschka, O. Knobl, Multifunktionale Profile - Bedingungen für die prozesssichere Herstellung durch Walzprofilieren, wt Werkstattstechnik online, Jahrgang 104 (2014), 609-613.

DOI: 10.37544/1436-4980-2014-10-609

[13] P. Groche, C. Müller, T. Traub, K. Butterweck, Experimental and Numerical Determination of Roll Forming Loads, steel research international, Volume 85, Issue 1, (2013) 112–122.

DOI: 10.1002/srin.201300190
