Simplified 7 DOF Model of Car Vertical Vibrations for Small Pitch and Roll Angles

Abstract:

This paper concerns a simplified 7 DOF model for car vertical vibrations. The classical 7 DOF of the considered 3D vertical model are: the vertical displacement of the gravity center of the car body, the roll and pitch angles of the car body and the four vertical displacements of the wheels centers. Using the x-y-z sequence of rotations parameterization, the Euler’s rotation equations concerning the roll and pitch angle are easily obtained. Small differences are observed between our car body rotation equations concerning the two pitch and roll angles and the same equations provided by Demić et al. [6]. For small pitch and roll angles, no differences were observed with respect with [6]. Also, no differences were observed concerning the other 5 dynamics equations of the 7 DOF model, the ones for the vertical displacements.The simplified 7 DOF car vertical dynamics model, comprising two rotation equations (for pitch and roll angles) and five dynamics equations concerning vertical displacements/accelerations, were integrated/simulated in Matlab. For small pitch and roll angles (a rather flat and smooth straight road profile was considered in our case study), the results obtained using the in-house 7 DOF model Matlab simulator are in very good agreement with the results provided by CARSIM.

• Periodical: Applied Mechanics and Materials (Volume 801)
• Pages: 136-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.801.136
• Online since: October 2015
• Authors: Dan Dumitriu*, Veturia Chiroiu, Ligia Munteanu
• Keywords: 7DOF Car Model, Carsim Software, MATLAB/SIMULINK, Pitch Angle, Roll Angle, Vertical Displacements, Vertical Dynamics

References

[1] Sh. Lajqi, S. Pehan, Designs and Optimizations of Active and Semi-Active Non-linear Suspension Systems for a Terrain Vehicle, Journal of Mechanical Engineering 58/12 (2012) 732-743.

DOI: 10.5545/sv-jme.2012.776

[2] S. Segla, S. Reich, Optimization and comparison of passive, active, and semi-active vehicle suspension systems, 12th IFToMM World Congress, Besançon (France), June 18-21, (2007).

[3] Mechanical Simulation Corporation, http: /www. carsim. com/, CARSIM 8. 1. 1 software, (2012).

[4] N. Truică, V. Nicolae, Un model matematic destinat studiului oscilaţiilor din transmisia şi suspensia unui automobil (parts I and II) (in Romanian), Simpozionul Mecanisme şi Transmisii Mecanice, Reşiţa (Romania), 1976, pp.786-796.

[5] T. Sireteanu, O. Gündisch, S. Părăian, Random vibrations of road vehicles (in Romanian: Vibraţiile aleatoare ale automobilelor), Editura Tehnică, Bucharest, (1981).

[6] M. Demić, Đ. Diligenski, I. Demić, M. Demić, A method of vehicle active suspension design, Forschung im Ingenieurwesen (Engineering Research) 70/3 (2006) 145-158.

DOI: 10.1007/s10010-006-0025-5

[7] D.N. Dumitriu, Car vertical dynamics 3D simulator using a 7 DOF model, Acta Technica Napocensis, Series: Applied Mathematics and Mechanics 55/III (2012) 647-650.

[8] D.N. Dumitriu, V. Chiroiu, L. Munteanu, Car vertical dynamics simulations using both an in-house 7 DOF model simulator and CARSIM commercial software, U.P.B. Sci. Bull. - Series D 77/1 (2015) 77-84.

[10] Mathworks Inc., Matlab User's Guide, Release (1997).
