Formalization of Discrete Mechatronic Systems with Negative Value Parameters

Abstract:

In the paper, the problem of designing of mechatronic discrete systems for vibration control has been investigated and generalized. As the design method, the synthesis has been used. Main focus of the paper is given to formalization of the mechatronic structures that contains elements with negative values on different stages of the synthesis process. The study is done based on different distributions methods of dynamical characteristics, dimensionless transformation and retransformation algorithm, simultaneously with verification of possible configurations of connections of piezostack actuators with external electric networks. As the result, various classifications of mechatronic discrete systems and general design constrains have been presented and discussed.

• Periodical: Applied Mechanics and Materials (Volumes 809-810)
• Pages: 105-110
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.809-810.105
• Online since: November 2015
• Authors: Andrzej Buchacz*, Damian Gałęziowski
• Keywords: Mechatronic Systems, Negative Parameters, Piezo, Synthesis, Vibration Control

References

[1] K. Białas, A. Buchacz, D. Gałęziowski: Modelling of discrete mechatronic systems with regard for damping function (in Polish), Modelling in Engineering. 16, 47 (2013) 31-35.

[2] M. Neubaer, R. Oleskiewicz, K. Popp, T. Krzyżynski: Optimization of damping and absorbing performance of shunted piezo elements utilizing negative capacitance, Journal of sound and vibration. 298, 1-2 (2006) 84-107.

DOI: 10.1016/j.jsv.2006.04.043

[3] A. Buchacz., M. Płaczek: Damping of mechanical vibrations using piezoelements, including influence of connection layer's properties on the dynamic characteristic, Solid State Phenomena. 147-149 (2009) 869-875.

DOI: 10.4028/www.scientific.net/ssp.147-149.869

[4] A. Dymarek: The reverse task of mechanical vibrating damped systems represented by graphs and structural numbers (in Polish), Doctoral Thesis, Silesian University of Technology, Gliwice, (2000).

[5] A. Buchacz, D. Galeziowski: Synthesis as a designing of mechatronic vibrating mixed systems. Journal of Vibroengineering. 14, 2 (2012) 553-559.

[6] K. Białas, A. Buchacz, D. Galeziowski: Passive and active vibration isolation methods in discrete mechatronic systems, Solid State Phenomena. 220-221 (2015) 15-20.

DOI: 10.4028/www.scientific.net/ssp.220-221.15

[7] K. Białas, A. Buchacz, D. Gałęziowski: Comparison of active and semi active damping of various mechatronic discrete systems, Int. J. of Materials and Product Technology. 50, 3/4 (2015) 340-355.

DOI: 10.1504/ijmpt.2015.068555

[8] K. Białas, A. Buchacz, D. Gałęziowski: The reverse task of discrete mechatronic vibration systems with negative stiffness and capacitance elements, Opole University of Technology Scientific Papers. 348, (2013) 13-14.

DOI: 10.1515/meceng-2015-0009

[9] L. Kashdan, C. Conner Seepersad, M. Haberman, P.S. Wilson: Design, fabrication and evaluation of negative stiffness elements using SLS, Rapid Prototyping Journal. 18, 3 (2012) 194-200.

DOI: 10.1108/13552541211218108

[10] D. Platus, Negative-stiffness-mechanism vibration isolation systems. Proceeding of SPIE, 1999, p.3786: 98-105.

[11] X. Han, M. Neubauer, J. Wallaschek: Improved piezoelectric switch shunt dumping technique using negative capacitance, Journal of Sound and Vibration. 332, 1 (2013) 7-16.

DOI: 10.1016/j.jsv.2012.08.001

[12] Fukada, M. Date, K. Kimura and others: Sound Isolation by Piezoelectric Polymer Films Connected to Negative Capacitance Circuits, IEEE Transactions on Dielectrics and Electrical Insulation. 11, 2 (2004) 328-333.

DOI: 10.1109/tdei.2004.1285904
