Comparison of Hybrid Metal-Composite Small-Pin Joints with Conventional Ones in Terms of Static and Fatigue Strength

Abstract:

The current research deals with special hybrid metal-composite joints (MCJ) which use thin sheet-metal reinforcement with small die-fixed pins (2-3 mm) embedded into the composite part of the joint. This technological trick significantly and positively influences strength of the metal-composite bolted joints loaded in out-of-plane direction. This fact was proved by comparison of pull-off static and fatigue tests results of MCJs with and without reinforcement.

• Periodical: Applied Mechanics and Materials (Volume 821)
• Pages: 479-485
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.821.479
• Online since: January 2016
• Authors: Ganna Beketova, Marina Shevtsova, Volodymyr Symonov*
• Keywords: Fatigue Strength, Metal-Composite Joint, Pull-Off Tests, Reinforcing Small-Pin Elements, Static Strength

References

[1] B. Kolesnikov, CFRP/titanium hybrid material for improving composite bolted joints, Composite Structures. 83 (2008) 368–380.

DOI: 10.1016/j.compstruct.2007.05.010

[2] T. Löbel, Enhanced tensile strength of composite joints by using staple-like pins: Working principles and experimental validation, Composite Structures. 106 (2013) 453–460.

DOI: 10.1016/j.compstruct.2013.06.020

[3] M. Pacchione, D. Furfari, U.S. Patent 2013/0149, 501 A1. (2013).

[4] I.S. Karpov, Joining of parts and units made of composite materials [in Russian], National Aerospace University "Kharkov Aviation Institute, Kharkov, (2006).

[5] T.M. Koh, Experimental determination of the structural properties and strengthening mechanisms of z-pinned composite T-joints, Composite Structures. 9 (2011) 2222–2230.

DOI: 10.1016/j.compstruct.2011.03.009

[6] T.M. Koh, Strengthening mechanics of thin and thick composite T-joints reinforced with z-pins Composites Part A: Applied Science and Manufacturing. 8 (2012) 1308–1317.

DOI: 10.1016/j.compositesa.2012.03.023

[7] Patent 91102 Ukraine, MPK7 E 04 B 1/49, Connection tooth"-like element / Beketova G.S., Gagaus F.M., Gumennikov V.V., Karpov I.S., Shevtsova M.A., Plotnikov V.I.; the applicant and owner National aerospace university - "Kharkiv Aviation Institute.

[8] A.P. Mouritz, Review of z-pinned composite laminates, Composites Part A: Applied Science and Manufacturing. – 12 (2007) 2383–2397.

DOI: 10.1016/j.compositesa.2007.08.016

[9] . I.S. Karpov, Design of composite parts and units [in Russian], National Aerospace University "Kharkov Aviation Institute, Kharkov, (2010).

[10] ASTM D3479/D 3479M-96 (Reapproved 2002). Standard Test Method for Tension-Tension Fatigue of Polymer Matrix Composite Materials. – app. Jun. 10 1996. – West Conshohocken: Committee on Standards, 2002. – 6 p.

DOI: 10.1520/d3479_d3479m-96

[11] ASTM E 739–91 (Reapproved 2004). Standard Practice for Statistical Analysis of Liner or Linearized Stess-Life (S-N) and Strain-Life (є-N) Fatigue Data. – app. E 739–91 (1998).
