Graphical Simulation System for Functional Analysis of a Parallel Robot for Transperineal Prostate Biopsy

Abstract:

The paper presents the functional analysis of a parallel robotic system used for transperineal prostate biopsy. A simulation system to study the robot functional analysis was developed using the integrated MATLAB software. Given the fact that the robotic system is used in a medical environment, it has to meet certain safety requirements indicated by the medical doctors. In order to fulfill these needs an appeal to complex simulation software has to be made to help choosing the best kinematic solution for the robotic system. The designed simulation software offers a correlation between the structure of the robot and the surrounding medical environment, pointing out its workspace and possible configurations that might harm the human patient during the biopsy.

• Periodical: Applied Mechanics and Materials (Volume 823)
• Pages: 101-106
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.823.101
• Online since: January 2016
• Authors: Doina Pîslă, Paul Tucan, Bogdan Gherman, Nicolae Crișan, Nicolae Plitea, Florin Covaciu
• Keywords: Kinematics, Parallel Robot, Robotic Assisted Transperineal Prostate Biopsy, Singularities, Workspace

References

[1] A. Jemal, R. Siegel, E. Ward, Cancer Statistics 2009, CA Cancer Clinic, (2009) 225-249.

[2] V. Ambert, The latest news in the diagnosis of prostate cancer, Romanian Medical Magazine, 58, (2011).

[3] Information on http: /www. ccss. ro/public_html, (2015).

[4] Information on http: /www. cancer. org , (2014).

[5] G. Fischer, Design of a Robot for Transperineal Prostate Needle Placement in MRI Scanner, IEEE Int. Conf. of Mechatronics, (2006).

DOI: 10.1109/icmech.2006.252593

[6] O. Bebek, M. Joong, H. Cavusoglu, Design of a Parallel Robot for Needle-Based Interventions on Small Animals. Mechatronics, IEEE/ASME Transactions, 18 (1), (2013) 62-73.

DOI: 10.1109/tmech.2011.2162427

[7] N. Plitea, A. Szilaghyi, D. Pisla, Kinematic Analysis of a new 5-DOF Modular Parallel Robot for Brachytherapy, Robotics and Computer Integrated Manufacturing, (31), (2014) 70-80.

DOI: 10.1016/j.rcim.2014.07.005

[8] N. Plitea, D. Pisla, C. Vaida, B. Gherman, A. Szilaghyi, B. Galdau, D. Cocorean, F. Covaciu, On the kinematics of a New Parallel Robot for Brachytherapy, Proceedings of the Romanian Academy, 15(4), (2014) 354-361.

DOI: 10.1007/978-3-319-01592-7_14

[9] N. Plitea, B. Gherman, P. Tucan, C. Vaida, C. Govor, On the kinematics of an innovative Parallel Robotic System for Transperineal Prostate Biopsy, 14th World Congress in Mechanisms and Machine Science, Taipei, Taiwan, (2015).

DOI: 10.1109/aqtr.2016.7501308

[10] N. Plitea, D. Pisla, C. Vaida, B. Gherman, P. Tucan, C. Govor, F. Covaciu, Family of innovative parallel robots for transperineal prostate biopsy, Patent pending , (2015).

DOI: 10.1109/aqtr.2016.7501308
