Non-Linear Numerical Analysis of Unreinforced Masonry Column and Masonry Column Reinforced by FRP Wrapping

Abstract:

A numerical model for unreinforced masonry columns and masonry columns reinforced by FRP wrapping is presented in this paper. Both, the bricks and the mortar are modeled as 3D continuum and to the interface between these two materials a non-linear contact law is assigned. The accurate 3D modeling of masonry units and mortar joints within the numerical model leads to high computational cost, but on the other hand, an appropriate analysis tool delivering detailed information about the behavior of masonry columns is obtained. A concrete damaged plasticity model was adopted for mortar and brick. External wrapping by a perfectly-adherent composite based strips and contact between strips and masonry is defined in the next step. The behavior of reinforcement was assumed isotropic and linearly elastic. The response and failure mechanism of masonry columns can be investigated. For all simulations the commercial software package ABAQUS was used. By comparison with results from experiments [1], the performance of the numerical model is evaluated and the obtained numerical results are discussed.

• Periodical: Applied Mechanics and Materials (Volume 827)
• Pages: 279-282
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.827.279
• Online since: February 2016
• Authors: Aneta Maroušková*
• Keywords: Finite Element Method, FRP Materials, Masonry, Numerical Analysis, Reinforcement

References

[1] Research project NAKI DF12P01OVV037 Progressive Non-Invasive Methods of the Stabilization, Conservation and Strengthening of Historic Structures and their Parts with fibre- and nanofibre-based Composite Materials,. The grant researcher is prof. Ing. Jiří Witzany, DrSc.

[2] J. Witzany, T. Čejka, R. Zigler. Efficiency and Critical Points of Strengthening Masonry Structures with FRP, in proc.: The Third Asia-Pacific Conference on FRP Structures (APFIS 2012), Japan Concrete Institute, Tokyo.

DOI: 10.1007/978-3-642-17487-2_208

[3] J. Witzany, T. Čejka, R. Zigler. Failure Mechanism of compressed short brick masonry columns confined with FRP strips, Construction and Buildings Materials 63 (2014) 180-188, DOI: 10. 1016/j. conbuildmat. 2014. 04. 041.

DOI: 10.1016/j.conbuildmat.2014.04.041

[4] J. Witzany, R. Zigler. The Analysis of the Effect of Strengthening Compressed Masonry Columns with Carbon Fabric, in proc.: The 7th International Conference on FRP Composites in Civil Engineering (CICE 2014), International Institute for FRP in Construction, Vancouver.

DOI: 10.1007/978-3-642-17487-2_208

[5] M. Mrozek, D. Mrozek, A. Warwrzynek. Numerical analysis of selection of the most effective configuration of CFRP composites reinforcement of masonry specimens, Composites: Part B 70 (2015) 189-200, doi: 10. 1016/j. compositesb. 2014. 11. 016.

DOI: 10.1016/j.compositesb.2014.11.016

[6] R. Fedele, G. Milani. A numerical insight into the response of masonry reinforced by FRP strips. The case of perfect adhesion, Composite Structures 92 (2010) 2345–2357, doi: 10. 1016/j. compstruct. 2010. 03. 014.

DOI: 10.1016/j.compstruct.2010.03.014

[7] R. Fedele, M. Scaioni, L. Barazzetti, G. Rosati, L. Biolzi. Delamination tests on CFRP-reinforced masonry pillars: Optical monitoring and mechanical modeling, Cement & Concrete Composites 45 (2014).

DOI: 10.1016/j.cemconcomp.2013.10.006
