SIMP for Complex Structures

Abstract:

Designing structures with frequency constraints is an important task in aerospace engineering. Aerodynamic loading, gust loading, and engine vibrations all impart dynamic loads upon an airframe. To avoid structural resonance and excessive vibration, the natural frequencies of the structure must be shifted away from the frequency range of any dynamic loads. Care must also be taken to ensure that the modal frequencies of a structure do not coalesce, which can lead to dramatic structural failure. So far in industry, no aircraft lifting surfaces are designed from the ground up with frequency optimisation as the primary goal. This paper will explore computational methods for achieving this task.This paper will present a topology optimisation algorithm employing the Solid Isotropic Microstructure with Penalisation (SIMP) method for the design of an optimal aircraft wing structure for rejection of frequency excitation.

• Periodical: Applied Mechanics and Materials (Volume 846)
• Pages: 535-540
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.846.535
• Online since: July 2016
• Authors: David J. Munk, David W. Boyd*, Gareth A. Vio
• Keywords: Natural Frequency, SIMP Method, Topology Optimisation, Vibration

References

[1] Krog, L.A. and Olhoff N. Optimum topology and reinforcement design of disk and plate structures with multiple stiffness and eigenfrequency objectives. Computers & Structures, 72(4): 535–563, (1999).

DOI: 10.1016/s0045-7949(98)00326-5

[2] Xie, Y.M. and Steven, G.P. A simple evolutionary procedure for structural optimization. Computers & structures, 49(5): 885–896, (1993).

DOI: 10.1016/0045-7949(93)90035-c

[3] Xie, Y.M. and Steven, G.P. A simple approach to structural frequency optimization. Computers & structures, 53(6): 1487–1491, (1994).

DOI: 10.1016/0045-7949(94)90414-6

[4] Zhao, C. Steven, G.P. and Xie, Y.M. Evolutionary natural frequency optimization of thin plate bending vibration problems. Structural optimization, 11(3-4): 244–251, (1996).

DOI: 10.1007/bf01197040

[5] Zhao, C. Steven, G.P. and Xie Y.M. Evolutionary natural frequency optimization of two-dimensional structures with additional non-structural lumped masses. Engineering Computations, 14(2): 233 - 251, (1997).

DOI: 10.1108/02644409710166208

[6] Zhao, C. B. Steven G.P. and Xie Y.M. Evolutionary optimization of maximizing the difference between two natural frequencies of a vibrating structure. Structural optimization 13. 2-3, (1997).

DOI: 10.1007/bf01199234

[7] Querin O.M. Steven G.P. and Xie Y.M. Evolutionary structural optimisation (eso) using a bidirectional algorithm. Engineering Computations, 15(8): 1031–1048, (1998).

DOI: 10.1108/02644409810244129

[8] Munk, D.J. Vio G.A. and Steven G.P. Topology and shape optimization methods using evolutionary algorithms: a review. Structural and Multidisciplinary Optimization. Published online: DOI 10. 1007/s00158-015-1261-9, (2015).

DOI: 10.1007/s00158-015-1261-9

[9] Rozvany G.I.N. A critical review of established methods of structural topology optimization. Structural and Multidisciplinary Optimization, 37(3): 217–237, (2009).

DOI: 10.1007/s00158-007-0217-0

[10] Rozvany G.I.N. Zhou M. and Birker T. Generalized shape optimization without homogenization. Structural optimization 4. 3-4: 250-252, (1992).

DOI: 10.1007/bf01742754

[11] Pedersen N.L. Maximization of eigenvalues using topology optimization. Structural and multidisciplinary optimization, 20(1): 2–11, (2000).

DOI: 10.1007/s001580050130

[12] Rozvany G.I.N. Aims, scope, methods, history and unified terminology of computeraided topology optimization in structural mechanics. Structural and Multidisciplinary Optimization, 21(2): 90–108, (2001).

DOI: 10.1007/s001580050174

[13] Stanford B.K. and Dunning P.D. Optimal topology of aircraft rib and spar structures under aeroelastic loads. AIAA Paper 2014-0633, (2014).

DOI: 10.2514/6.2014-0633

[14] Dunning P.D. Stanford, B.K. and Kim A.H. Coupled aerostructural topology optimization using a level set method for 3D aircraft wings. Structural and Multidiciplinary Optimization, 51: 1113-1132, (2015).

DOI: 10.1007/s00158-014-1200-1

[15] Maute, K. and Allen M. Conceptual design of aeroelastic structures by topology optimization. Structural and multidisciplinary optimization. 27(1): 27-42, (2004).

DOI: 10.1007/s00158-003-0362-z

[16] Krog, L. Grihon, S. and Marasco A. Smart design of structures through topology optimization. 8th world congress on structural and multidisciplinary optimization, Lisbon, Putugal, (2009).

[17] Oktay, E. Akay, H.U. and Sehitoglu, O.T. Three-dimensional structural topology optimization of aerial vehicles under aerodynamic loads. Computers and fluids 92(1): 225-232, (2014).

DOI: 10.1016/j.compfluid.2013.11.018

[18] Huang, X. Zuo Z.H. and Xie Y.M. Evolutionary topological optimization of vibrating continuum structures for natural frequencies. Computers & structures88. 5: 357-364, (2010).

DOI: 10.1016/j.compstruc.2009.11.011
