Failure Analysis of Injection Pipe in Diesel-Hydrogenated Unit

Abstract:

An injection pipe of diesel-hydrogenated unit exploded in a refinery of Shandong Province. In order to analyze the causes of the pipe explosion, the authors measured the pipe wall thickness, sampled the fractured pipe, observed the fracture of the samples by metallographic microscope, surveyed the pipe service environment, and calculated the pipe burst pressure. As the exploded pipe deformed very seriously and no any significant original defect in the fracture was observed, the failure reason of the pipe might be over pressure due to heat tracing by continuous supply of steam during the unit shutdown. Meanwhile, measures were suggested to avoid the similar accidents.

• Periodical: Applied Mechanics and Materials (Volume 853)
• Pages: 529-533
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.853.529
• Online since: September 2016
• Authors: Li Bo Fan, Guo Xin Zhang, Yan Peng Qu, Yan Liu, Wei Qiang Wang*
• Keywords: Diesel-Hydrogenated Unit, Failure Analysis, Injection Pipe, Pipe Explosion

References

[1] Ministry of Metallurgical Industry of the PRC. GB/T 13298-1991, Metal-Inspection method of microstructure. Beijing: Standards Press of China, (1991).

[2] China Iron and Steel Association. GB/T 224-2008, Determination of depth of decarburization of steels. Beijing: Standards Press of China, (2008).

[3] China Iron and Steel Association. GB9948-2013, Seamless steel tubes for petroleum cracking. Beijing: Standards Press of China, (2013).

[4] China Standardization Committee on Boilers and Pressure Vessels. GB150-2011, Pressure vessels. Beijing: Standards Press of China, (2011).

[5] Yueshen Wu, Qingfang Liu. Boiler and pressure vessel safety engineering. Beijing: Beijing Institute of Economy Press, (1991).
