Computer Simulation Analysis of Bending Stress for Face Gear with a New Type Fillet Tooth Surface

Abstract:

Bending stress is a principal factor that defines the fatigue life of face gear. A new tooth surface structure with circular arc of fillet surface for the face gear has been developed. A method of processing or cutting of fillet surfaces of helical face gear by application of a shaper with tooth rounded top has also been represented. The bending stress of the tooth of face gear with new surface structure has been performed by computer simulation. Two versions of finite element model of tooth surfaces of face gear are generated by application of numerical technology. One version is based on the cutting shaper with tooth top shaper corner and another version is with addendum rounded top. Tooth contact analysis (TCA) and loaded tooth contact analysis (LTCA) for the two versions of face gear drives with helical spur gear are also considered. The results of simulation show that the bending stress of tooth surface of the face gear with fillet surface generated by the rounded top of the shaper is 12% lower than the first version’s.

You might also be interested in these eBooks

Advances in Power Transmission Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 86)

Pages:

411-414

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.86.411

Citation:

Cite this paper

Online since:

August 2011

Authors:

Yun Bo Shen, Jie Gao, Wen Qiang Ding

Keywords:

Bending Stress, Face Gear, Rounded Top, Shaper

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] F.L. Litvin, I. Gonzalez-Perez, A. Fuentes etc.: Methods Appl. Mech. Engrg, Vol. 194 (2005), p.3870.

Google Scholar

[2] George Bibel. NASA/CR- 2002-211277.

Google Scholar

[3] M. Gabiccini, M. Guiggiani and F.D. Puccio: Proceedings of the 11th world congress in Mechanism and Machine Science, April (2004), p.1.

Google Scholar

[4] Handbook on Gear Manufacture editor committee: Handbook on Gear Manufacture. (China Machine Press, Beijing, China 1997).

Google Scholar

[5] Y.B. Shen, Z.D. Fang, N. Zhao: Mechanical Transmission, Vol. 93 (2009), p.9.

Google Scholar

[6] Y.B. Shen: The Design Theory of Tooth Surface and Technology of Gear Shaping of Face Gear Drive. Doctor Thesis, (Northwestern Polytechnical University, Xi'an: 2009).

Google Scholar
