The Research on General Modeling Methods of the Complicated Transmission Based on Hypergraph Theory

Abstract:

In order to be adapt to the increasingly large complex transmission modeling, this paper propose methods of building generalized modeling through applying hypergraph theory to the complex fixed axis transmission, the planetary gear transmission and the integrated transmission. The author established conversion rules between the real transmission to hypergraph, and found feasibility algorithm for relay route auto search. Hypergraph theory can be further used to realize automatic generation of general dynamics model.
