A Finite Element Analysis on Metal Ball Effect on Dynamics of a Ball Bearing

Abstract:

The bearings are widely used in the rotating machinery systems to support the mechanical, structural for system. In a high rotating speed, the spindle to be stable rotating is dependent on a high performance bearing. Therefore, the dynamic characteristic of a ball bearing is very importance and need to study. In this work, the dynamic characteristic of a ball bearing is focused to study. Because the geometric of ball bearing are so complex, the finite element analysis is employed to investigate. By using the finite element analysis software ANSYS, the bearings meshed model can be setup. The dynamic properties, natural frequency and mode shape of ball and global system, can be studied to improve the high spindle rotating stable performance. Numerical indicates that the stress, strain and dynamics of the ball bearing system can be investigated in this finite element model.

• Periodical: Applied Mechanics and Materials (Volume 875)
• Pages: 100-104
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.875.100
• Online since: January 2018
• Authors: Bo Wun Huang*, Jia Sheng Chen, Zhi Yin Huang, Nan Wen Lin
• Keywords: Ball Bearing, Finite Element Analysis, Metal

References

[1] M. J. Goodwin, Dynamics of Rotor-Bearing System, Unwin Hyman, London, (1989).

[2] J. A. Brandon, K. J. H. Al-Shareef, On The Applicability of Modal and Response Representations in The Dynamic Analysis of Machine Tool Spindle Bearing Systems, Proc. Inst. Mech. Eng. B J. Eng. Manuf. 205 (1991) 139-145.

DOI: 10.1243/pime_proc_1991_205_061_02

[3] B. R. Jorgensen, Y. C. Shin, Dynamics of Spindle-Bearing Systems at High Speeds Including Cutting Load Effects, J Manuf. Sci E. T ASME. 120 (1998) 387-394.

DOI: 10.1115/1.2830138

[4] W. R. Wang, C. N. Chang, Dynamic Analysis and Design of a Machine Tool Spindle-Bearing System, J. Vib. Acoust. T ASME. 116 (1994) 280-285.

[5] R. G. Parker, C. J. Mote, Vibration and Coupling Phenomena in Asymmetric Disk-Spindle Systems, J. Appl. Mech. -T ASME. 63 (1996) 953-961.

DOI: 10.1115/1.2787252

[6] I. Y. Shen, Closed-Form Forced Response of a Damped, Rotating, Multiple Disks/Spindle System, J. Appl. Mech. -T ASME. 64 (1997) 343-352.

DOI: 10.1115/1.2787313

[7] F. T. Barwell, Bearing System, Principles and Practice, Oxford University Press, New York, (1979).

[8] M. Chinta, A. B. Palazzolo, Stability and Bifurcation of Rotor Motion in a Magnetic Bearing, J. Sound Vib. 214(5) (1998) 793-803.

DOI: 10.1006/jsvi.1998.1549

[9] C. Delprete, G. Genta, A. Repaci, Numerical Simulation of the Dynamic Behavior of Rotors on Active Magnetic Bearings, Proc. of the 7th International Symposium on Transport Phenomena and Dynamics of Rotating Machinery, Honolulu, Hawaii, USA, (1998).

[10] M. Komori, T. Hamasaki, Improvement and Evaluation of Bearing Stiffness in High Tc Superconducting Magnetic Bearing, IEEE Trans. Appl. Superconduct. 11(1) (2001) 1677-1680.

DOI: 10.1109/77.920104

[11] H. Chang, S. C. Chung, Integrated Design of Radial Active Magnetic Bearing Systems Using Genetic Algorithms, Mechatron. 12(1) (2002) 19-36.

DOI: 10.1016/s0957-4158(00)00068-4

[12] J. C. Cheung, The Modal Analysis of Hard Disk Drive Spindle System with Ball Bearings, National Changhua University of Education, Department of Mechatronics Engineering, Master Thesis, (2004).

[13] Y. H. Chou, Study on Mounting and Dismounting of Roller Bearing with Performance Measurement, Kun Shan University, Department of Mechatronics Engineering, Master Thesis, (2015).

[14] http: /www. eb-bearing. com. tw/?f=Deep-groove-ball-bearing.
